| # | Part Number | Description | Qty | Status |
|---|
| - |
804986A1 |
GASKET/SEAL SET Powerhead
|
1 |
|
| - |
858257T18 |
POWERHEAD ASSEMBLY
|
1 |
superseded
|
| 1 |
8742A20 |
TANK ASSEMBLY Remote Oil Complete
|
1 |
superseded
|
| 1 |
87421 |
TANK Oil
|
1 |
|
| 10 |
11332 |
O-RING (2.225 x .210)
|
1 |
|
| 11 |
99802 |
TUBE Oil Pick Up
|
1 |
|
| 12 |
99439 |
HOSE (114.00 Inches) Oil Line
|
1 |
|
| 13 |
816311T |
TIE STRAP (8.00 Inches)
|
5 |
|
| 14 |
878105 |
CHECK VALVE Crankcase
|
1 |
superseded
|
| 15 |
NSS |
NOT SOLD SEPARATE Plug
|
1 |
|
| 16 |
994436 |
RESERVOIR Oil
|
1 |
|
| 17 |
NSS |
NOT SOLD SEPARATE Decal - Reservoir Warning
|
1 |
|
| 18 |
43300A5 |
CAP ASSEMBLY Oil Reservoir
|
1 |
|
| 19 |
99022A1 |
FLOAT ASSEMBLY
|
1 |
superseded
|
| 2 |
12335A1 |
BRACKET KIT Oil Tank Hold Down
|
1 |
|
| 20 |
99265 |
PUSH NUT
|
1 |
|
| 21 |
43307 |
GASKET Reservoir Cap
|
1 |
superseded
|
| 22 |
816311T |
TIE STRAP (8.00 Inches)
|
4 |
|
| 23 |
82381455 |
TUBING (25.00 Inches Bulk) Cut 4.750 Inches
|
1 |
|
| 24 |
69020 |
SCREW (#10-32 x .875)
|
3 |
superseded
|
| 25 |
42118 |
WASHER Oil Reservoir Screw
|
6 |
|
| 26 |
42117 |
GROMMET Oil Reservoir Screw
|
3 |
|
| 27 |
42116 |
BUSHING Oil Reservoir Screw
|
3 |
|
| 28 |
NSS |
NOT SOLD SEPARATE Plug - Yellow
|
1 |
|
| 29 |
424254 |
FITTING Special - Oil Tubing
|
1 |
superseded
|
| 3 |
12323A1 |
CORD/HOOK KIT
|
1 |
|
| 30 |
830756109 |
HOSE (57.00 Inches Bulk) Cut 6.00 Inches
|
1 |
superseded
|
| 31 |
1938512 |
LINK ASSEMBLY Throttle Lever To Oil Pump
|
1 |
|
| 32 |
32228 |
SCREW (#10-32 x .625)
|
1 |
|
| 32 |
41507 |
SCREW (#10-32 x 1.120)
|
1 |
|
| 33 |
815699T |
PUMP ASSEMBLY Oil
|
1 |
|
| 34 |
11379 |
O-RING
|
1 |
|
| 35 |
8141032 |
BUSHING Worm
|
1 |
|
| 36 |
859112 |
BEARING Drive Gear
|
1 |
|
| 37 |
48462 |
O-RING (.614 x .070)
|
1 |
|
| 38 |
8591111 |
GEAR Driven
|
1 |
|
| 4 |
12320 |
BRACKET Hold Down
|
2 |
|
| 5 |
79968 |
SCREW (#12-11 x .750)
|
4 |
|
| 6 |
43298A2 |
CAP ASSEMBLY Oil Tank
|
1 |
|
| 7 |
11332 |
O-RING (2.225 x .210) Cap
|
1 |
|
| 8 |
816190A4 |
OIL PICK UP ASSEMBLY Without Sender Adapter
|
1 |
|
| 9 |
43298A2 |
CAP ASSEMBLY Housing Adaptor
|
1 |
|
