| # | Part Number | Description | Qty | Status |
|---|
| - |
804986A1 |
GASKET/SEAL SET Powerhead
|
1 |
|
| - |
858257T18 |
POWERHEAD ASSEMBLY
|
1 |
superseded
|
| 1 |
15930A33 |
PUMP ASSEMBLY Fuel
|
1 |
disc.
|
| 10 |
NSS |
NOT SOLD SEPARATE Spring
|
1 |
|
| 11 |
NSS |
NOT SOLD SEPARATE Spring End Cap
|
1 |
|
| 12 |
987691 |
GASKET Base
|
1 |
superseded
|
| 13 |
144303 |
BASE Fuel Pump
|
1 |
|
| 14 |
987752 |
PLATE Fuel Pump
|
1 |
|
| 15 |
996642 |
FITTING Elbow 90 Degree (.125-27 x .250) Nylon
|
1 |
|
| 16 |
82104540 |
SCREW (M5 x 40) Fuel Pump
|
2 |
|
| 17 |
816311T |
TIE STRAP (8.00 Inches)
|
2 |
|
| 18 |
851975 |
FITTING Elbow - 45 Degree - Brass (.125-27)
|
1 |
|
| 19 |
875271 |
FITTING 90 Degree - Brass (.125-27)
|
1 |
|
| 2 |
857005A1 |
DIAPHRAGM KIT
|
1 |
|
| 20 |
996642 |
FITTING Elbow 90 Degree (.125-27 x .250) Nylon
|
1 |
|
| 21 |
82130050 |
SCREW (M6 x 50) Fuel Pump To Crankcase
|
2 |
|
| 22 |
830757130 |
TUBING (.312) (70.00 Inches Bulk) Cut 6.00 Inches
|
1 |
superseded
|
| 23 |
55098 |
J CLIP
|
1 |
superseded
|
| 24 |
828151A1 |
RELAY ASSEMBLY
|
1 |
superseded
|
| 25 |
818968 |
BUSHING
|
1 |
superseded
|
| 26 |
818967 |
GROMMET
|
1 |
|
| 27 |
828102 |
BRACKET
|
1 |
superseded
|
| 28 |
72761 |
WASHER (.203 x .562 x .060) Stainless Steel
|
1 |
|
| 29 |
41507 |
SCREW (#10-32 x 1.120)
|
1 |
|
| 3 |
NSS |
NOT SOLD SEPARATE Check Valve Disk
|
2 |
|
| 30 |
834985 |
GROMMET
|
3 |
superseded
|
| 31 |
8318701 |
BUSHING
|
6 |
|
| 32 |
72761 |
WASHER (.203 x .562 x .060) Stainless Steel
|
3 |
|
| 33 |
41507 |
SCREW (#10-32 x 1.120)
|
3 |
|
| 34 |
852523 |
ELBOW (.125-27)
|
1 |
|
| 35 |
852521T1 |
PUMP ASSEMBLY Fuel - Electric
|
1 |
|
| 36 |
852546T |
FILTER Fuel
|
1 |
superseded
|
| 37 |
F698772 |
CLAMP Worm Gear
|
3 |
|
| 38 |
32228 |
SCREW (#10-32 x .625)
|
2 |
|
| 39 |
72761 |
WASHER (.203 x .562 x .060) Stainless Steel
|
2 |
|
| 4 |
NSS |
NOT SOLD SEPARATE Retainer
|
2 |
|
| 40 |
83192339 |
HOSE (11.00 Inches Bulk) Cut 9.500 Inches
|
1 |
superseded
|
| 41 |
34059 |
NUT (#10-32)
|
2 |
superseded
|
| 42 |
855615T |
PLATE Electric Fuel Pump Mount
|
1 |
disc.
|
| 43 |
34059 |
NUT (#10-32)
|
1 |
superseded
|
| 5 |
NSS |
NOT SOLD SEPARATE Boost Gasket
|
1 |
|
| 6 |
NSS |
NOT SOLD SEPARATE Spring End Cap
|
1 |
|
| 7 |
NSS |
NOT SOLD SEPARATE Spring
|
1 |
|
| 8 |
NSS |
NOT SOLD SEPARATE Diaphragm
|
2 |
|
| 9 |
NSS |
NOT SOLD SEPARATE Pulse Gasket
|
1 |
|
