| # | Part Number | Description | Qty | Status |
|---|
| 1 |
808643 |
REMOTE CONTROL (RH - Forward Cable Entry)
|
1 |
disc.
|
| 1 |
808644 |
REMOTE CONTROL (RH - Aft Cable Entry)
|
1 |
disc.
|
| 10 |
820687 |
SWIVEL BRACKET Swivel
|
1 |
disc.
|
| 11 |
820688 |
BLOCK Dwell
|
1 |
disc.
|
| 12 |
13438 |
NUT (.250-28)
|
1 |
superseded
|
| 13 |
820689 |
SPRING Dwell Block
|
1 |
disc.
|
| 14 |
820690 |
ARM Shift
|
1 |
disc.
|
| 15 |
820691 |
CAM Switch Actuation
|
1 |
disc.
|
| 16 |
F17036 |
WASHER
|
2 |
disc.
|
| 17 |
F17155 |
BOLT (.250-28 x .500)
|
2 |
disc.
|
| 18 |
F17016 |
PIVOT Cable Terminal
|
2 |
disc.
|
| 19 |
F17149 |
COTTER PIN Cotter
|
2 |
disc.
|
| 2 |
820682 |
LEVER ASSEMBLY Hand
|
1 |
superseded
|
| 20 |
820692 |
ARM Throttle
|
1 |
disc.
|
| 21 |
820693 |
SWITCH ASSEMBLY
|
1 |
disc.
|
| 22 |
820694 |
LOCKWASHER Internal (#4) Internal
|
2/3 |
disc.
|
| 23 |
820695 |
SCREW (#10 x 1.250)
|
3 |
disc.
|
| 24 |
820696 |
INSERT Interlock
|
1 |
disc.
|
| 25 |
820697 |
BRACKET Switch Mounting
|
1 |
disc.
|
| 26 |
820698 |
SCREW (#4-40 x .750)
|
2 |
disc.
|
| 27 |
820699 |
SCREW (#4-40 x .312)
|
1 |
disc.
|
| 28 |
820701 |
SCREW (#4-40 x .375)
|
1 |
disc.
|
| 29 |
63683 |
NUT (.112-40)
|
3 |
disc.
|
| 3 |
F455690 |
SET SCREW (.312-18 x .3125) Set
|
1 |
disc.
|
| 30 |
820705 |
SCREW (#4 x .625)
|
2 |
disc.
|
| 31 |
820700 |
HARDWARE PACKAGE (With Template And Manual)
|
1 |
disc.
|
| 4 |
F17081 |
BALL Black Black
|
1 |
disc.
|
| 5 |
820683 |
HANGER ASSEMBLY
|
1 |
disc.
|
| 6 |
F8058 |
LOCKWASHER Internal (#10)
|
4 |
disc.
|
| 7 |
820684 |
SCREW (#10-32 x 1.500)
|
4 |
disc.
|
| 8 |
820685 |
SCREW (.250-28 x .875)
|
1 |
disc.
|
| 9 |
820686 |
WASHER
|
1 |
disc.
|
