| # | Part Number | Description | Qty | Status |
|---|
| - |
809175A1 |
SEAL/GASKET SET Drive Housing
|
1 |
superseded
|
| - |
820238A11 |
HOUSING KIT Drive (Complete) (Painted) (No Impeller)
|
1 |
disc.
|
| 1 |
820326 |
WASHER Thrust
|
1 |
disc.
|
| 10 |
28634A1 |
SCREW KIT
|
1 |
superseded
|
| 11 |
805726 |
O-RING Rubber
|
1 |
superseded
|
| 12 |
75677 |
SCREW (.250-20 x .620)
|
2 |
disc.
|
| 14 |
820599 |
TAB Locking
|
1 |
disc.
|
| 15 |
820531 |
BRACKET Shift (Painted)
|
1 |
disc.
|
| 16 |
814101 |
NUT (.250-20) Stainless Steel
|
1 |
superseded
|
| 17 |
8200281 |
SWIVEL Cable Clamp
|
1 |
|
| 18 |
F405457 |
SCREW Pivot
|
1 |
disc.
|
| 19 |
F2217-1 |
SCREW AND LOCKWASHER (#10-24 x .375)
|
2 |
disc.
|
| 2 |
828029T |
IMPELLER Stainless Steel - 5 Blade (Splined)
|
1 |
superseded
|
| 20 |
846341 |
BRACKET Cable
|
1 |
|
| 21 |
40108100 |
SCREW (M10 x 100) Hex Flange - Stainless Steel
|
4 |
superseded
|
| 22 |
820469A1 |
NOZZLE ASSEMBLY (Painted)
|
1 |
superseded
|
| 22A |
826701 |
FITTING Nozzle
|
2 |
|
| 23 |
820444T |
ANODE
|
1 |
superseded
|
| 24 |
4010835 |
SCREW (M10 x 35) Hex Flange - Stainless Steel
|
2 |
|
| 25 |
820343A4 |
RUDDER KIT (Painted)
|
1 |
superseded
|
| 26 |
820289 |
BUSHING Pivot
|
2 |
superseded
|
| 27 |
8205031 |
ANODE
|
1 |
|
| 28 |
824830 |
SCREW (M6 x 13)
|
1 |
|
| 29 |
93702 |
WASHER (.250 External Star)
|
1 |
|
| 3 |
820243T1 |
RING Wear (Painted)
|
1 |
superseded
|
| 30 |
820336 |
BOLT Pivot
|
4 |
|
| 31 |
4010725 |
SCREW (M8 x 25)
|
3 |
|
| 32 |
820462 |
LEVER Steering (Painted)
|
1 |
superseded
|
| 33 |
820483A2 |
GATE ASSEMBLY (Painted)
|
1 |
superseded
|
| 34 |
820289 |
BUSHING
|
2 |
superseded
|
| 35 |
824467 |
PIN Clevis
|
1 |
disc.
|
| 36 |
29245 |
WASHER (.281 x .500 x .060) Stainless Steel
|
1 |
superseded
|
| 37 |
21071 |
COTTER PIN
|
1 |
superseded
|
| 38 |
8205031 |
ANODE
|
1 |
|
| 39 |
824830 |
SCREW (M6 x 13)
|
1 |
|
| 4 |
20195 |
O-RING
|
1 |
superseded
|
| 40 |
93702 |
WASHER (.250 External Star)
|
1 |
|
| 44 |
820564 |
STOP Reverse Gate
|
2 |
|
| 45 |
36001 |
WASHER
|
2 |
|
| 46 |
4007154 |
SCREW (M8 x 30)
|
2 |
|
| 47 |
4010845 |
SCREW (M10 x 45) Hex Flange - Stainless Steel
|
2 |
|
| 48 |
820601 |
TAB Locking Bolt
|
1 |
disc.
|
| 49 |
820509 |
WASHER Impeller Shaft
|
1 |
disc.
|
| 5 |
73379 |
PLUG (.250-18)
|
1 |
superseded
|
| 50 |
820508 |
NUT Impeller Shaft
|
1 |
disc.
|
| 51 |
826700 |
HOSE Syphon
|
1 |
disc.
|
| 52 |
816311 |
TIE STRAP (8.00 Inches)
|
2 |
superseded
|
| 6 |
820245A3 |
STATOR ASSEMBLY (Painted)
|
1 |
superseded
|
| 7 |
820430 |
BUSHING Stator Rear
|
2 |
|
| 8 |
819396 |
SEAL Crankshaft Lower
|
2 |
|
| 9 |
73379 |
PLUG (.250-18)
|
1 |
superseded
|
