| # | Part Number | Description | Qty | Status |
|---|
| 1 |
8202421 |
PLATE Adapter (Painted)
|
1 |
disc.
|
| 10 |
8204511 |
STUD (M8 x 55)
|
4 |
|
| 11 |
824015 |
CUP Barrel Retainer Barrel Retainer
|
1 |
|
| 12 |
826702 |
SIPHON BREAK
|
2 |
superseded
|
| 13 |
98889 |
LATCH Control Cable
|
1 |
|
| 14 |
820452 |
FITTING Water Hose
|
1 |
superseded
|
| 15 |
816311 |
TIE STRAP (8.00 Inches)
|
2 |
superseded
|
| 16 |
828091 |
FITTING Syphon Hose
|
2 |
disc.
|
| 17 |
1678978 |
HOSE (9.00 Feet Bulk) Syphon (Cut to 42.00 Inch Length)
|
2 |
superseded
|
| 18 |
23567 |
CLIP Syphon Hose
|
2 |
|
| 19 |
820448 |
HOSE ASSEMBLY Water Inlet
|
1 |
disc.
|
| 2 |
38101 |
O-RING (.674 x .103)
|
1 |
|
| 20 |
820238A11 |
HOUSING KIT Drive (Complete) (Painted) (No Impeller)
|
1 |
disc.
|
| 20 |
820238A12 |
HOUSING ASSEMBLY Drive (Painted)
|
1 |
disc.
|
| 21 |
826359 |
PIN Dowel
|
2 |
|
| 22 |
94038 |
SEAL Oil
|
2 |
|
| 23 |
820292 |
BEARING Ball
|
1 |
|
| 24 |
23721 |
RING Retaining
|
1 |
superseded
|
| 25 |
823611 |
FOAM Exhaust Deflector
|
2 |
superseded
|
| 27 |
8202581 |
GASKET Drive Housing
|
1 |
|
| 28 |
8233581 |
STUD (M10 x 72)
|
5 |
disc.
|
| 29 |
826292 |
NUT (M10) Brass/Nickel Plated
|
8 |
|
| 3 |
820339 |
BRACKET Towershaft Bearing
|
1 |
disc.
|
| 30 |
826365 |
NUT (M8)
|
4 |
|
| 31 |
820640 |
STUD (M10 x 55)
|
2 |
|
| 32 |
820639 |
STUD (M10 x 98)
|
1 |
disc.
|
| 33 |
63186 |
FITTING (.125-27) Syphon Drain Hose
|
2 |
disc.
|
| 34 |
820663250 |
GROMMET (.250) Pump Mount
|
AR |
|
| 34 |
820663375 |
GROMMET (.375) Pump Mount
|
AR |
disc.
|
| 34 |
820663500 |
GROMMET (.500) Pump Mount
|
AR |
|
| 35 |
827433 |
BAFFLE ASSEMBLY Exhaust
|
2 |
superseded
|
| 36 |
NSS |
NOT SOLD SEPARATE WASHER (12-40023-17) (No Longer Required)
|
2 |
|
| 37 |
827587 |
SCREW (M8 x 1.25)
|
2 |
disc.
|
| 38 |
826365 |
NUT (M8)
|
2 |
|
| 39 |
826703 |
FILTER Syphon Hose
|
2 |
superseded
|
| 4 |
4010610 |
SCREW (M6 x 10) Stainless Steel
|
2 |
|
| 40 |
1678978 |
HOSE (9.00 Feet Bulk) Syphon (Cut to 18.00 Inch Length)
|
2 |
superseded
|
| 41 |
8204631 |
BRACKET Steering (Painted)
|
1 |
disc.
|
| 42 |
4010716 |
SCREW (M8 x 16)
|
3 |
|
| 43 |
8205911 |
TAB Locking
|
1 |
disc.
|
| 45 |
8202531 |
SCREEN Inlet (Painted)
|
1 |
disc.
|
| 46 |
824830 |
SCREW (M6 x 13) (With Nylon Patch)
|
4 |
|
| 47 |
824829 |
SCREW (M6 x 20) (With Nylon Patch)
|
2 |
|
| 5 |
F40689-1 |
BEARING Towershaft Lower
|
1 |
disc.
|
| 52 |
28634A1 |
SCREW KIT
|
2 |
superseded
|
| 53 |
805726 |
O-RING Rubber
|
2 |
superseded
|
| 54 |
825406A2 |
RIDE PLATE KIT (Painted)
|
1 |
superseded
|
| 55 |
820489T1 |
SEAL Ride Plate
|
1 |
superseded
|
| 56 |
824830 |
SCREW (M6 x 13) (With Nylon Patch)
|
8 |
|
| 57 |
824829 |
SCREW (M6 x 20) (With Nylon Patch)
|
2 |
|
| 58 |
809175A1 |
SEAL/GASKET SET Drive Housing
|
1 |
superseded
|
| 59 |
35280 |
WASHER (.255 x .620 x .030) Stainless Steel
|
OPT |
|
| 6 |
45175 |
WASHER (.406 x .750 x .104)
|
10 |
superseded
|
| 60 |
415825 |
CLAMP Nylon
|
4 |
|
| 61 |
415827 |
CLAMP Nylon
|
2 |
superseded
|
| 7 |
35047 |
SCREW (.375-16 x 1.250) Stainless Steel
|
10 |
|
| 8 |
820244A6 |
COVER KIT Drive Housing (Painted)
|
1 |
disc.
|
| 9 |
33145 |
O-RING (1.984 x .139)
|
1 |
superseded
|
