| # | Part Number | Description | Qty | Status |
|---|
| 1 |
819484A2 |
TOWERSHAFT KIT
|
1 |
superseded
|
| 10 |
19931088 |
SCREW (#10-24 x .875) (With Dri Loc)
|
2 |
disc.
|
| 11 |
F40689-1 |
BEARING Lower Towershaft
|
1 |
disc.
|
| 12 |
20110 |
NUT (#10-32)
|
1 |
|
| 13 |
819002 |
LINK Throttle
|
1 |
disc.
|
| 14 |
68219 |
NUT (#10-32) Stainless Steel
|
2 |
|
| 15 |
8177471 |
BEARING With Ball Joint
|
1 |
superseded
|
| 16 |
F698192 |
CAM Throttle
|
1 |
superseded
|
| 17 |
F269319 |
BEARING Throttle Cam
|
2 |
disc.
|
| 18 |
72008 |
NUT (.250-20)
|
1 |
superseded
|
| 19 |
13194 |
RING Retaining
|
1 |
|
| 2 |
819513 |
BUSHING Upper
|
1 |
disc.
|
| 20 |
F499035 |
END Control Rod (To Towershaft)
|
1 |
|
| 21 |
F499026 |
SWIVEL Control Rod End
|
2 |
disc.
|
| 22 |
F7009 |
NUT (#10-24)
|
2 |
disc.
|
| 23 |
F499036-1 |
END Control Rod Control Rod (To Trigger)
|
1 |
|
| 24 |
F85445-1 |
ROD Spark Control Spark Control
|
1 |
|
| 25 |
F2015 |
NUT (.250-28) Stainless Steel
|
1 |
|
| 26 |
820565 |
STUD Throttle Arm
|
1 |
disc.
|
| 27 |
29245 |
WASHER (.281 x .500 x .060) Stainless Steel
|
2 |
superseded
|
| 28 |
814101 |
NUT (.250-20) Stainless Steel
|
1 |
superseded
|
| 29 |
21071 |
COTTER PIN
|
1 |
superseded
|
| 3 |
38489 |
PIN Roll
|
7 |
|
| 30 |
820078 |
BEARING Center
|
1 |
disc.
|
| 4 |
F1504 |
SCREW (.250-20 x 1.250)
|
1 |
|
| 5 |
64015 |
NUT (.250-20)
|
1 |
|
| 6 |
F1727 |
RIVET Nylon
|
1 |
disc.
|
| 7 |
F1856 |
WASHER
|
1 |
disc.
|
| 8 |
819533 |
SPRING Throttle Return
|
1 |
disc.
|
| 9 |
8177471 |
BEARING With Ball Joint
|
2 |
superseded
|
