| # | Part Number | Description | Qty | Status |
|---|
| - |
809183A1 |
GASKET SET Powerhead
|
1 |
superseded
|
| - |
818154A23 |
POWERHEAD ASSEMBLY
|
1 |
superseded
|
| 1 |
817870A1 |
COVER KIT Fuel Pump (With Plug)
|
1 |
disc.
|
| 10 |
F177330 |
VALVE Fuel Pump
|
1 |
superseded
|
| 11 |
F84792 |
GASKET Center Valve
|
1 |
|
| 12 |
F686300 |
SPRING Pump Boost
|
1 |
disc.
|
| 13 |
89302 |
WASHER (.203 x .406 x .040)
|
2 |
|
| 14 |
88865 |
SCREW (#10-24 x .750) Stainless Steel
|
2 |
disc.
|
| 15 |
26992 |
LOCKWASHER (.250) Stainless Steel
|
4 |
|
| 16 |
F1504 |
SCREW (.250-20 x 1.250)
|
4 |
|
| 17 |
F695801 |
FITTING
|
1 |
disc.
|
| 18 |
823606 |
GASKET Fuel Pump Bowl
|
1 |
|
| 19 |
F438653 |
SCREEN Fuel Pump
|
1 |
|
| 2 |
F658803 |
GASKET Spacer Plate
|
1 |
|
| 20 |
88865 |
SCREW (#10-24 x .750) Stainless Steel
|
1 |
disc.
|
| 21 |
98254 |
SCREW (.250-20 x .620)
|
3 |
|
| 22 |
F695500 |
BOWL Sediment
|
1 |
disc.
|
| 23 |
F743314 |
ELBOW Recirculating
|
1 |
disc.
|
| 24 |
820500 |
GASKET Fuel Pump
|
1 |
superseded
|
| 25 |
78968 |
LOCKWASHER Internal (.250) (Ground Screw)
|
2 |
|
| 26 |
28636 |
SCREW (.250-20 x .750) (Ground Wire)
|
1 |
|
| 27 |
82722881 |
HOSE (38.00 Inches Bulk)
|
1 |
disc.
|
| 28 |
F698772 |
CLAMP Worm Gear
|
2 |
|
| 29 |
99127109 |
LINE (57.00 Inches Bulk) (Cut to 4.500 Inch Length)
|
1 |
superseded
|
| 3 |
F7009 |
NUT (#10-24)
|
2 |
disc.
|
| 4 |
F658836 |
SPACER Fuel Pump
|
1 |
disc.
|
| 5 |
820490 |
GASKET Fuel Pump
|
1 |
|
| 6 |
F438747 |
DIAPHRAGM Fuel Pump
|
1 |
|
| 7 |
F686096 |
RETAINER Booster Spring
|
1 |
|
| 8 |
819843A1 |
BODY ASSEMBLY Fuel Pump
|
1 |
superseded
|
| 9 |
28430 |
SCREW (#6-32 x .25)
|
2 |
|
| _ |
820581A1 |
PUMP KIT
|
1 |
disc.
|
