| # | Part Number | Description | Qty | Status |
|---|
| 1 |
NLA |
No Longer Available Swivel Bracket
|
1 |
|
| 10 |
858869 |
NUT (.875-14)
|
1 |
|
| 11 |
NLA |
No Longer Available Clamp
|
1 |
|
| 12 |
NLA |
No Longer Available Screw
|
1 |
|
| 12A |
30164 |
WASHER (.192 x .375 x .0312) Stainless Steel
|
1 |
|
| 13 |
75275 |
CLAMP
|
1 |
|
| 14 |
NLA |
No Longer Available Nut
|
1 |
|
| 15 |
NLA |
No Longer Available Brace
|
1 |
|
| 16 |
NLA |
No Longer Available Pin
|
1 |
|
| 17 |
NLA |
No Longer Available Handle
|
1 |
|
| 18 |
25191 |
COTTER PIN
|
2 |
|
| 19 |
36001 |
WASHER
|
1 |
|
| 2 |
87735 |
SEAL Oil
|
1 |
|
| 20 |
NLA |
No Longer Available Link
|
1 |
|
| 21 |
NLA |
No Longer Available Spring
|
1 |
|
| 22 |
NLA |
No Longer Available Pin
|
1 |
|
| 23 |
78854 |
WAVE WASHER
|
1 |
|
| 24 |
86580A1 |
YOKE ASSEMBLY Bottom
|
1 |
disc.
|
| 25 |
NLA |
No Longer Available Washer (Use where Applicable
|
1 |
|
| 26 |
67684 |
RING Retaining
|
1 |
|
| 3 |
818764 |
BUSHING
|
2 |
|
| 32 |
67670 |
WASHER
|
1 |
disc.
|
| 33 |
840792A1 |
SWIVEL PIN ASSEMBLY
|
1 |
disc.
|
| 34 |
78689 |
SCREW (.437-20 x 7.50)
|
2 |
superseded
|
| 35 |
78687T |
MOUNT
|
2 |
disc.
|
| 35 |
77326 |
MOUNT (HEAVY DUTY)
|
2 |
|
| 36 |
66921 |
WASHER
|
2 |
|
| 37 |
814432 |
WASHER
|
2 |
superseded
|
| 38 |
82671015 |
NUT (.437-20) Stainless Steel
|
2 |
superseded
|
| 39 |
NLA |
No Longer Available Bumper
|
1 |
|
| 4 |
33466 |
O-RING
|
1 |
|
| 40 |
NLA |
No Longer Available Steering Link
|
1 |
|
| 41 |
14000 |
SCREW (.375-24 x 1.25)
|
1 |
superseded
|
| 42 |
826709113 |
NUT (.375-24) Stainless Steel
|
1 |
superseded
|
| 43 |
34931 |
WASHER (.406 x .734 x .063) Stainless Steel
|
2 |
|
| 44 |
826709113 |
NUT (.375-24) Stainless Steel
|
1 |
superseded
|
| 45 |
NLA |
No Longer Available Cover
|
2 |
|
| 46 |
28635 |
SCREW (.250-20 x .620) Stainless Steel
|
4 |
|
| 47 |
26992 |
LOCKWASHER (.250) Stainless Steel
|
4 |
|
| 5 |
67668 |
SPACER
|
1 |
disc.
|
| 6 |
74036 |
FITTING Grease
|
3 |
superseded
|
| 8 |
NLA |
No Longer Available Tilt Tube
|
1 |
|
| 9 |
NLA |
No Longer Available Shim
|
2 |
|
