| # | Part Number | Description | Qty | Status |
|---|
| - |
8M0131208 |
COMM CAP ASSEMBLY FW, With Seals and Bushing Use With 40# Thrust and Greater Motors
|
1 |
disc.
|
| 1 |
8M0105541 |
HEAD AND HANDLE ASSEMBLY Freshwater (Black) 1.25 Inch Column
|
1 |
|
| 10 |
NSS |
NOT SOLD SEPARATE MOTOR
|
1 |
|
| 11 |
8M4002641 |
PROPELLER KIT 3 Blade with Wrench
|
1 |
|
| 12 |
8M0105503 |
HARDWARE KIT, PROPELLER Fresh Water
|
1 |
disc.
|
| 13 |
NSS |
NOT SOLD SEPARATE Washer
|
1 |
|
| 14 |
MBR10202T |
PIN Prop Drive (.156 x 1.00)
|
1 |
|
| 15 |
8M0058717 |
CABLE ASSEMBLY
|
1 |
disc.
|
| 15 |
8M0124147 |
CABLE ASSEMBLY
|
1 |
disc.
|
| 16 |
8M0119628 |
HYSOL EPOXY ADHESIVE 50ml
|
1 |
|
| 17 |
8M0124164 |
DECAL 70 lb. FW
|
1 |
disc.
|
| 2 |
8M0105540 |
HEAD ASSEMBLY Freshwater (Black) 1.25 Inch Column
|
1 |
|
| 3 |
8M0105538 |
HANDLE ASSEMBLY
|
1 |
|
| 4 |
8M4002637 |
SWITCH 5 Speed
|
1 |
superseded
|
| 4 |
8M0124142 |
SWITCH 5 Speed
|
1 |
|
| 5 |
NSS |
NOT SOLD SEPARATE SCREW
|
2 |
|
| 6 |
8M4002640 |
COLLAR, Depth 1.25 inch
|
1 |
disc.
|
| 6 |
8M0124150 |
COLLAR, Depth
|
1 |
disc.
|
| 7 |
8M0124149 |
FRICTION COLLAR
|
1 |
|
| 8 |
8M0096833 |
COLUMN 50 INCH
|
1 |
|
| 8 |
8M0086305 |
COLUMN (54 Inches) White Cut to 50 Inches
|
1 |
|
| 9 |
8M0092074 |
BOW MOUNT FW
|
1 |
disc.
|
