| # | Part Number | Description | Qty | Status |
|---|---|---|---|---|
| 1 | 99417A2 |
СТАРТЕР В СБОРЕ (Delco Remy №1998317) [0A000000] THRU [0D831100] STARTER MOTOR ASSEMBLY (Delco Remy #1998317) [0A000000] THRU [0D831100] |
1 | superseded |
| 1 | 812429A2 |
СТАРТЕР В СБОРЕ (Delco Remy №9000763) [0D831101] THRU [0F353099] STARTER MOTOR ASSEMBLY (Delco Remy #9000763) [0D831101] THRU [0F353099] |
1 | superseded |
| 1 | 806963A2 |
СТАРТЕР В СБОРЕ (Delco Remy №PG-260) [0F353100] THRU [0Z999999] STARTER MOTOR ASSEMBLY (Delco Remy #PG-260) [0F353100] THRU [0Z999999] |
1 | superseded |
| 10 | 400211 |
ГАЙКА (M5), нержавеющая сталь (Delco Remy №1998317) [0A000000] THRU [0D831100] NUT (M5) Stainless Steel (Delco Remy #1998317) [0A000000] THRU [0D831100] |
1 | |
| 10 | 400211 |
ГАЙКА (M5), нержавеющая сталь (Delco Remy №9000763) [0D831101] THRU [0F353099] NUT (M5) Stainless Steel (Delco Remy #9000763) [0D831101] THRU [0F353099] |
1 | |
| 10 | 400211 |
ГАЙКА (M5), нержавеющая сталь (Delco Remy №PG-260) [0F353100] THRU [0Z999999] NUT (M5) Stainless Steel (Delco Remy #PG-260) [0F353100] THRU [0Z999999] |
1 | |
| 11 | 26996 |
СТОПОРНАЯ ШАЙБА (№10), нержавеющая сталь (Delco Remy №1998317) [0A000000] THRU [0D831100] LOCKWASHER (#10) Stainless Steel (Delco Remy #1998317) [0A000000] THRU [0D831100] |
1 | |
| 11 | 26996 |
СТОПОРНАЯ ШАЙБА (№10), нержавеющая сталь (Delco Remy №9000763) [0D831101] THRU [0F353099] LOCKWASHER (#10) Stainless Steel (Delco Remy #9000763) [0D831101] THRU [0F353099] |
1 | |
| 11 | 26996 |
СТОПОРНАЯ ШАЙБА (№10), нержавеющая сталь (Delco Remy №PG-260) [0F353100] THRU [0Z999999] LOCKWASHER (#10) Stainless Steel (Delco Remy #PG-260) [0F353100] THRU [0Z999999] |
1 | |
| 12 | 79695 |
ЧЕХОЛ Изолятор – черный BOOT Insulator - Black |
1 | superseded |
| 13 | 58333 |
СКОБА Передний – регулировка генератора BRACE Front-Alternator Adjusting |
1 | |
| 14 | 29198 |
ВИНТ И СТОПОРНАЯ ШАЙБА (0.312-18 x 0.875) SCREW AND LOCKWASHER (.312-18 x .875) |
1 | |
| 15 | 26168 |
ШАЙБА WASHER |
1 | |
| 16 | 98261 |
ВИНТ (0.375-16 x 0.750) SCREW (.375-16 x .750) |
1 | |
| 17 | 20553 |
ШАЙБА (0.406 x 0.734 x 0.063) WASHER (.406 x .734 x .063) |
1 | |
| 18 | 37626 |
ВИНТ (0.375-24 x 4.250) SCREW (.375-24 x 4.250) |
1 | |
| 19 | 28105 |
ШАЙБА WASHER |
1 | |
| 2 | 98192 |
РЕГУЛИРОВОЧНАЯ ПРОКЛАДКА (Delco Remy №1998317) [0A000000] THRU [0D831100] SHIM (Delco Remy #1998317) [0A000000] THRU [0D831100] |
AR | disc. |
| 20 | 63894 |
ПРОСТАВКА SPACER |
1 | disc. |
| 21 | 20553 |
ШАЙБА (0.406 x 0.734 x 0.063) WASHER (.406 x .734 x .063) |
1 | |
| 22 | 23161 |
ГАЙКА (.375-24) NUT (.375-24) |
1 | |
| 23 | 16738A1 |
КРОНШТЕЙН BRACKET |
1 | disc. |
| 24 | 12244 |
ВИНТ (0.375-16 x 1.00) SCREW (.375-16 x 1.00) |
2 | superseded |
| 24A | 5790811 |
РУКАВ (Общая длина 10.00") SLEEVE (10.00 Inches Bulk) |
2 | |
| 25 | 92497A3 |
ГЕНЕРАТОР В СБОРЕ (55 ампер) (Prestolite или Mando №AR-150) ALTERNATOR ASSEMBLY (55 Ampere) (Prestolite or Mando #AR-150) |
1 | superseded |
| 25 | 817119A4 |
ГЕНЕРАТОР (Mando №AC-155603) ALTERNATOR (Mando #AC-155603) |
1 | |
| 26 | 96457 |
ШАЙБА Фенольный (0.27 x 0.81 x 0.062) (Prestolite или Mando №AR-150) WASHER Phenolic (.27 x .81 x .062) (Prestolite or Mando #AR-150) |
1 | |
| 26 | 96457 |
ШАЙБА Фенольный (0.27 x 0.81 x 0.062) Фенольный (Mando №AC-155603) WASHER Phenolic (.27 x .81 x .062) Phenolic (Mando #AC-155603) |
1 | |
| 27 | 21272 |
СТОПОРНАЯ ШАЙБА (0.250) (Prestolite или Mando №AR-150) LOCKWASHER (.250) (Prestolite or Mando #AR-150) |
1 | |
| 27 | 29245 |
ШАЙБА (0.281 x 0.500 x 0.060), нержавеющая сталь (Mando №AC-155603) WASHER (.281 x .500 x .060) Stainless Steel (Mando #AC-155603) |
1 | superseded |
| 28 | 64015 |
ГАЙКА (0.250-20) (Prestolite или Mando №AR-150) NUT (.250-20) (Prestolite or Mando #AR-150) |
1 | |
| 28 | 79989 |
ГАЙКА (№10-24), нержавеющая сталь (Mando №AC-155603) NUT (#10-24) Stainless Steel (Mando #AC-155603) |
1 | |
| 28 | 94330 |
ГАЙКА (0.250-20), латунь (Mando №AC-155603) NUT (.250-20) Brass (Mando #AC-155603) |
1 | |
| 3 | 94435 |
БОЛТ (0.375-16 x 4.600) (Delco Remy №1998317) [0A000000] THRU [0D831100] BOLT (.375-16 x 4.600) (Delco Remy #1998317) [0A000000] THRU [0D831100] |
1 | superseded |
| 3 | 8053431 |
БОЛТ (4.6562) (Delco Remy №9000763) [0D831101] THRU [0F353099] BOLT (4.6562) (Delco Remy #9000763) [0D831101] THRU [0F353099] |
1 | disc. |
| 3 | 8053432 |
ВИНТ (0.375-16 x 4.33) (Delco Remy №PG-260) [0F353100] THRU [0Z999999] SCREW (.375-16 x 4.33) (Delco Remy #PG-260) [0F353100] THRU [0Z999999] |
1 | |
| 4 | 8053433 |
БОЛТ (1.9375) (Delco Remy №1998317) [0A000000] THRU [0D831100] BOLT (1.9375) (Delco Remy #1998317) [0A000000] THRU [0D831100] |
1 | |
| 4 | 8053433 |
БОЛТ (1.9375) (Delco Remy №9000763) [0D831101] THRU [0F353099] BOLT (1.9375) (Delco Remy #9000763) [0D831101] THRU [0F353099] |
1 | |
| 4 | 8053434 |
БОЛТ (1.6875) (Delco Remy №PG-260) [0F353100] THRU [0Z999999] BOLT (1.6875) (Delco Remy #PG-260) [0F353100] THRU [0Z999999] |
1 | |
| 5 | 87300T |
КРОНШТЕЙН (Delco Remy №1998317) [0A000000] THRU [0D831100] BRACKET (Delco Remy #1998317) [0A000000] THRU [0D831100] |
1 | disc. |
| 6 | 12244 |
ВИНТ (0.375-16 x 1.00) (Delco Remy №1998317) [0A000000] THRU [0D831100] SCREW (.375-16 x 1.00) (Delco Remy #1998317) [0A000000] THRU [0D831100] |
1 | superseded |
| 7 | 72008 |
ГАЙКА (0.250-20) (Delco Remy №1998317) [0A000000] THRU [0D831100] NUT (.250-20) (Delco Remy #1998317) [0A000000] THRU [0D831100] |
1 | superseded |
| 7 | 72008 |
ГАЙКА (0.250-20) (Delco Remy №9000763) [0D831101] THRU [0F353099] NUT (.250-20) (Delco Remy #9000763) [0D831101] THRU [0F353099] |
1 | superseded |
| 8 | 97159 |
ШАЙБА (Delco Remy №9000763) [0D831101] THRU [0F353099] WASHER (Delco Remy #9000763) [0D831101] THRU [0F353099] |
1 | disc. |
| 9 | 15874 |
ГАЙКА (M10) (Delco Remy №1998317) [0A000000D831100] & Up NUT (M10) (Delco Remy #1998317) [0A000000D831100] & Up |
1 | |
| 9 | 15874 |
ГАЙКА (M10) (Delco Remy №9000763) [0D831101] THRU [0F353099] NUT (M10) (Delco Remy #9000763) [0D831101] THRU [0F353099] |
1 | |
| 9 | 806949 |
ГАЙКА (M8-1.5) (Delco Remy №PG-260) [0F353100] THRU [0Z999999] NUT (M8-1.5) (Delco Remy #PG-260) [0F353100] THRU [0Z999999] |
1 |
