| # | Part Number | Description | Qty | Status |
|---|
| - |
43433A01 |
GUIDE KIT
|
1 |
|
| - |
95846A3 |
TUBE ASSEMBLY Steering (Non Power Steering)
|
1 |
|
| 1 |
8M0138839 |
PLATE ASSEMBLY Transom
|
1 |
|
| 10 |
865436A02 |
SHIFT CABLE
|
1 |
superseded
|
| 11 |
31700 |
SCREW (.250-28 x .750)
|
1 |
superseded
|
| 12 |
43433 |
GUIDE
|
1 |
superseded
|
| 13 |
43436 |
ANCHOR
|
1 |
|
| 14 |
20518 |
SET SCREW (#8-32)
|
2 |
superseded
|
| 15 |
38473 |
WRAPPING Spiral
|
1 |
|
| 16 |
861632T |
INSERT (3.28 Inches)
|
1 |
|
| 16 |
14705 |
INSERT (.78 Inches)
|
1 |
|
| 17 |
96400 |
TUBE Steering (Non Power Steering)
|
1 |
|
| 18 |
95846 |
SWIVEL BLOCK (Non Power Steering)
|
1 |
|
| 19 |
47525 |
NUT (.875-14) (Non Power Steering)
|
1 |
|
| 2 |
8M0113173 |
BOLT
|
2 |
|
| 20 |
95803 |
BUSHING (Non Power Steering)
|
2 |
|
| 21 |
865232 |
TOOL Shift Slide Stabilizer Shift Slide
|
1 |
|
| 3 |
42254 |
WASHER
|
2 |
|
| 4 |
97934 |
SCREW (.500-20 x 5.370) Special
|
2 |
superseded
|
| 5 |
89665 |
WASHER Stainless Steel
|
2 |
|
| 6 |
99299 |
SPACER (.520 x .870 x .630)
|
2 |
|
| 7 |
8M0096564 |
WASHER Rubber U Shape
|
2 |
|
| 8 |
33734 |
LOCKWASHER (.500)
|
2 |
|
| 9 |
863332 |
NUT (.500-20) Aluminum
|
2 |
|
