| # | Part Number | Description | Qty | Status |
|---|---|---|---|---|
| 1 | 816496 |
НАСОС Масло PUMP Oil |
1 | superseded |
| 10 | 49955 |
ПРОКЛАДКА DRAIN SCREW GASKET DRAIN SCREW |
1 | superseded |
| 11 | 34500 |
ВИНТ (0.312-18 x 0.625) OIL PAN (5/16-18) SCREW (.312-18 x .625) OIL PAN (5/16-18) |
20 | |
| 13 | 14070 |
ВИНТ (0.250-20 x 0.625) OIL PAN SCREW (.250-20 x .625) OIL PAN |
2 | |
| 15 | 14606T |
ТРУБА OIL LEVEL GAUGE TUBE OIL LEVEL GAUGE |
1 | superseded |
| 16 | 14607 |
ЩУП OIL LEVEL (DIPSTICK) DIPSTICK OIL LEVEL (DIPSTICK) |
1 | superseded |
| 17 | 90309 |
ЗАЖИМ OIL LEVEL TUBE CLIP OIL LEVEL TUBE |
1 | disc. |
| 18 | 76926 |
ВИНТ (0.375-16 x 0.875) CLIP TO BRACKET SCREW (.375-16 x .875) CLIP TO BRACKET |
1 | |
| 19 | 35048 |
СТОПОРНАЯ ШАЙБА (0.375) CLIP SCREW LOCKWASHER (.375) CLIP SCREW |
1 | |
| 2 | 49108 |
ШПИЛЬКА OIL PUMP TO CYLINDER BLOCK STUD OIL PUMP TO CYLINDER BLOCK |
1 | superseded |
| 20 | 814510 |
АРМАТУРА OIL PAN (PORT) REINFORCEMENT OIL PAN (PORT) |
1 | disc. |
| 20 | 814511 |
АРМАТУРА OIL PAN (STARBOARD) REINFORCEMENT OIL PAN (STARBOARD) |
1 | disc. |
| 3 | 49149 |
ВАЛ OIL PUMP TO DISTRIBUTOR SHAFT OIL PUMP TO DISTRIBUTOR |
1 | superseded |
| 4 | 52193 |
РУКАВ OIL PUMP SHAFT SLEEVE OIL PUMP SHAFT |
1 | disc. |
| 7 | 19221 |
ПОДДОН В СБОРЕ (8 QUART) PAN ASSEMBLY (8 QUART) |
1 | superseded |
| 8 | 52550 |
КОМПЛЕКТ ПРОКЛАДОК OIL PAN GASKET SET OIL PAN |
1 | |
| 9 | 49956 |
ВИНТ Слив OIL PAN DRAIN SCREW Drain OIL PAN DRAIN |
1 |
