| # | Part Number | Description | Qty | Status |
|---|---|---|---|---|
| - | 13218A1 |
КОМПЛЕКТ ПРОКЛАДОК [0A398941] THRU [0D725499] GASKET SET [0A398941] THRU [0D725499] |
1 | disc. |
| - | 808730A92 |
КОМПЛЕКТ ПРОКЛАДОК [0D725500] THRU [0D937011] GASKET SET [0D725500] THRU [0D937011] |
1 | superseded |
| 1 | 816185A17 |
ЛОНГ-БЛОК В СБОРЕ 420 And 425 Models - See Note 1 [0A398941] THRU [0D725499] LONG BLOCK ASSEMBLY 420 And 425 Models - See Note 1 [0A398941] THRU [0D725499] |
1 | disc. |
| 1 | 847705A13 |
ЛОНГ-БЛОК В СБОРЕ 425 Models - See Note 1 [0D725500] THRU [0D937011] LONG BLOCK ASSEMBLY 425 Models - See Note 1 [0D725500] THRU [0D937011] |
1 | superseded |
| 1 | 9638 |
БЛОК ЦИЛИНДРА В СБОРЕ 420 And 425 Models - See Note 2 [0A398941] THRU [0D725499] CYLINDER BLOCK ASSEMBLY 420 And 425 Models - See Note 2 [0A398941] THRU [0D725499] |
1 | disc. |
| 1 | 801999 |
БЛОК В СБОРЕ Цилиндр 425 Models - See Note 2 [0D725500] THRU [0D937011] BLOCK ASSEMBLY Cylinder 425 Models - See Note 2 [0D725500] THRU [0D937011] |
1 | disc. |
| 10 | 61728 |
ЦЕПЬ Timing [0A398941] THRU [0D725499] CHAIN Timing [0A398941] THRU [0D725499] |
1 | disc. |
| 10 | 811580 |
ЦЕПЬ Timing [0D725500] THRU [0D937011] CHAIN Timing [0D725500] THRU [0D937011] |
1 | superseded |
| 11 | 61726 |
ЗВЕЗДОЧКА Camshaft [0A398941] THRU [0D725499] SPROCKET Camshaft [0A398941] THRU [0D725499] |
1 | disc. |
| 11 | 811578 |
ЗВЕЗДОЧКА Camshaft [0D725500] THRU [0D937011] SPROCKET Camshaft [0D725500] THRU [0D937011] |
1 | disc. |
| 12 | 61727 |
ЗВЕЗДОЧКА Crankshaft [0A398941] THRU [0D725499] SPROCKET Crankshaft [0A398941] THRU [0D725499] |
1 | disc. |
| 12 | 811579 |
ЗВЕЗДОЧКА Crankshaft [0D725500] THRU [0D937011] SPROCKET Crankshaft [0D725500] THRU [0D937011] |
1 | superseded |
| 13 | 35339 |
ВИНТ (0.312-18 x 0.750) SCREW (.312-18 x .750) |
3 | superseded |
| 14 | 39167 |
ШАЙБА WASHER |
3 | superseded |
| 15 | 35312 |
ШТИФТ Штифт (1/4" в диаметре) (.250) PIN Dowel (1/4 In. Diameter) (.250) |
1 | superseded |
| 2 | 48340 |
ПРОБКА (0.250-18 x 0.41) PLUG (.250-18 x .41) |
4 | superseded |
| 2 | 48358 |
ПРОБКА (0.375) PLUG (.375) |
2 | superseded |
| 3 | 36382 |
ФИТИНГ (0.250-18 x 0.62), латунь FITTING (.250-18 x .62) Brass |
2 | |
| 4 | 37478 |
ПРОБКА Expansion (1.750 Inch) PLUG Expansion (1.750 Inch) |
8 | superseded |
| 5 | 52190 |
ШТИФТ PIN |
4 | |
| 6 | 94140 |
КОМПЕНСАЦИОННАЯ ЗАГЛУШКА EXPANSION PLUG |
1 | |
| 7 | 85684 |
НАБОР ПОДШИПНИКОВ BEARING SET |
1 | |
| 8 | 93722 |
СЪЕМНИК LIFTER |
16 | superseded |
| 9 | 7892 |
РАСПРЕДЕЛИТЕЛЬНЫЙ ВАЛ CAMSHAFT |
1 | disc. |
