| # | Part Number | Description | Qty | Status |
|---|---|---|---|---|
| 1 | 87290A4 |
КОРПУС В СБОРЕ HOUSING ASSEMBLY |
1 | |
| 10 | 47441A1 |
КРЫШКА Thermostat COVER Thermostat |
1 | |
| 11 | 33389 |
ВИНТ (4.25") Thermostat Housing SCREW (4.25 Inches) Thermostat Housing |
2 | superseded |
| 11 | 48130 |
ВИНТ (0.375-16 x 4.500) Thermostat Housing With Lifting Eye SCREW (.375-16 x 4.500) Thermostat Housing With Lifting Eye |
2 | disc. |
| 12 | 35048 |
СТОПОРНАЯ ШАЙБА (0.375) LOCKWASHER (.375) |
2 | |
| 13 | 98477A2 |
КЛАПАН В СБОРЕ Thermostat Housing VALVE ASSEMBLY Thermostat Housing |
1 | |
| 14 | 3322070 |
РУКАВ (Общая длина 48.00") Tee to Exhaust Elbows (17") HOSE (48.00 Inches Bulk) Tee to Exhaust Elbows (17") |
2 | superseded |
| 15 | 32780 |
ЗАЖИМ Hose Attaching CLAMP Hose Attaching |
8 | superseded |
| 16 | 87116 |
РУКАВ Thermostat Cover to Exhaust Manifold PORT HOSE Thermostat Cover to Exhaust Manifold PORT |
1 | superseded |
| 17 | 41940 |
РУКАВ Thermostat Cover to Exhaust Manifold STARBOARD HOSE Thermostat Cover to Exhaust Manifold STARBOARD |
1 | |
| 18 | 47715 |
ЗАЖИМ Hose Attaching CLIP Hose Attaching |
1 | disc. |
| 19 | 88794 |
РУКАВ Thermostat Housnig to Fluid Cooler With Power Steering HOSE Thermostat Housnig to Fluid Cooler With Power Steering |
1 | |
| 2 | 47511 |
РУКАВ Thermostat Housing SLEEVE Thermostat Housing |
1 | |
| 20 | 41642A3 |
РУКАВ FLUID COOLER (3/4" I.D.) With Power Steering HOSE FLUID COOLER (3/4" I.D.) With Power Steering |
1 | |
| 21 | 32780 |
ЗАЖИМ HOSE ATTACHING With Power Steering CLAMP HOSE ATTACHING With Power Steering |
4 | superseded |
| 22 | 99356A2 |
ОХЛАДИТЕЛЬ В СБОРЕ POWER STEERING FLUID With Power Steering COOLER ASSEMBLY POWER STEERING FLUID With Power Steering |
1 | superseded |
| 24 | 56328A1 |
КРОНШТЕЙН FLUID COOLER (SHORT) With Power Steering BRACKET FLUID COOLER (SHORT) With Power Steering |
1 | |
| 25 | 638203 |
КРОНШТЕЙН FLUID COOLER (LONG) With Power Steering BRACKET FLUID COOLER (LONG) With Power Steering |
1 | superseded |
| 26 | 60300 |
ВИНТ (0.250-28 x 0.750) Fluid Cooler Bracket With Power Steering SCREW (.250-28 x .750) Fluid Cooler Bracket With Power Steering |
2 | |
| 27 | 30506 |
ГАЙКА (0.250-28) With Power Steering NUT (.250-28) With Power Steering |
2 | |
| 28 | 98033A3 |
РУКАВ Thermostat Housing (3/4" I.D.) Without Power Steering HOSE Thermostat Housing (3/4" I.D.) Without Power Steering |
1 | disc. |
| 29 | 32780 |
ЗАЖИМ Hose Attaching Without Power Steering CLAMP Hose Attaching Without Power Steering |
2 | superseded |
| 3 | 32803 |
ПРОБКА Труба (0.375-18), латунь PLUG Pipe (.375-18) Brass |
2 | superseded |
| 30 | 87108 |
РУКАВ Литой Thermostat Housing to Water Pump HOSE Molded Thermostat Housing to Water Pump |
1 | superseded |
| 31 | 87268 |
ЗАЖИМ Hose Attaching CLAMP Hose Attaching |
2 | superseded |
| 32 | 12552 |
ПОДЪЕМНАЯ СКОБА (USE 10-48130) LIFTING EYE (USE 10-48130) |
1 | |
| 4 | 53045 |
ПРОКЛАДКА Thermostat Housing GASKET Thermostat Housing |
1 | superseded |
| 5 | 59137 |
ТЕРМОСТАТ (140 градусов) THERMOSTAT (140 Degrees) |
1 | superseded |
| 6 | 47510 |
ПРОКЛАДКА Thermostat GASKET Thermostat |
1 | |
| 7 | 47508 |
РУКАВ Thermostat SLEEVE Thermostat |
1 | superseded |
| 8 | 41812 |
ПРОКЛАДКА Thermostat Cover GASKET Thermostat Cover |
1 |
