| # | Part Number | Description | Qty | Status |
|---|---|---|---|---|
| 1 | 44364A1 |
КРОНШТЕЙН В СБОРЕ MOUNTING - ENGINE (FRONT) BRACKET ASSEMBLY MOUNTING - ENGINE (FRONT) |
2 | superseded |
| 10 | 20739 |
ГАЙКА (.750-16) JAM - ENGINE MOUNT BASE NUT (.750-16) JAM - ENGINE MOUNT BASE |
6 | |
| 11 | 68102 |
СТОПОРНАЯ ШАЙБА (0.750) MOUNTING BRACKET LOCKWASHER (.750) MOUNTING BRACKET |
2 | |
| 12 | 12657 |
ЛЕПЕСТКОВАЯ ШАЙБА TAB WASHER |
2 | |
| 2 | 37612 |
ВИНТ (0.375-16 x 1.250) MOUNTING BRACKET TO ENGINE SCREW (.375-16 x 1.250) MOUNTING BRACKET TO ENGINE |
5 | |
| 3 | 35048 |
СТОПОРНАЯ ШАЙБА (0.375) MOUNTING BRACKET SCREW LOCKWASHER (.375) MOUNTING BRACKET SCREW |
5 | |
| 3 | 46132 |
ШАЙБА MOUNTING BRACKET SCREW WASHER MOUNTING BRACKET SCREW |
1 | |
| 4 | 64066 |
ШПИЛЬКА (0.375-16 x 2.750), специальный MOUNTING BRACKET TO ENGINE STARBOARD STUD (.375-16 x 2.750) Special MOUNTING BRACKET TO ENGINE STARBOARD |
1 | superseded |
| 5 | 78945 |
J-ОБРАЗНЫЙ ФИКСАТОР Harness Support-WIRING HARNESS STARBOARD J CLAMP Harness Support-WIRING HARNESS STARBOARD |
1 | |
| 6 | 35048 |
СТОПОРНАЯ ШАЙБА (0.375) MOUNTING BRACKET STUD STARBOARD LOCKWASHER (.375) MOUNTING BRACKET STUD STARBOARD |
2 | |
| 7 | 32219 |
ГАЙКА (.375-16) MOUNTING BRACKET STUD STARBOARD NUT (.375-16) MOUNTING BRACKET STUD STARBOARD |
1 | |
| 8 | 57369 |
ПРОСТАВКА MOUNTING STUD SPACER MOUNTING STUD |
1 | |
| 9 | 66284A2 |
БАЗА В СБОРЕ ENGINE MOUNT BASE ASSEMBLY ENGINE MOUNT |
2 |
