| # | Part Number | Description | Qty | Status |
|---|---|---|---|---|
| - | 65184A88 |
КОМПЛЕКТ ПРОКЛАДОК Двигатель (Note: 454 Magnum Long Block - 18706A1) GASKET SET Engine (Note: 454 Magnum Long Block - 18706A1) |
1 | disc. |
| 1 | 9639 |
БЛОК ЦИЛИНДРА В СБОРЕ (Note: 454 Magnum Short Block-18706A1) CYLINDER BLOCK ASSEMBLY (Note: 454 Magnum Short Block-18706A1) |
1 | disc. |
| 10 | 75588 |
ЦЕПЬ CAMSHAFT TIMING CHAIN CAMSHAFT TIMING |
1 | superseded |
| 11 | 86481 |
ЗВЕЗДОЧКА CAMSHAFT SPROCKET CAMSHAFT |
1 | disc. |
| 12 | 86482 |
ЗВЕЗДОЧКА CRANKSHAFT TIMING SPROCKET CRANKSHAFT TIMING |
1 | disc. |
| 13 | 34505 |
ВИНТ (0.312-18 x 0.875) CAMSHAFT TIMING SPROCKET SCREW (.312-18 x .875) CAMSHAFT TIMING SPROCKET |
3 | |
| 14 | 35312 |
ШТИФТ Штифт (1/4" в диаметре) DOWEL - CAMSHAFT SPROCKET PIN Dowel (1/4 In. Diameter) DOWEL - CAMSHAFT SPROCKET |
1 | superseded |
| 2 | 48340 |
ПРОБКА (0.250-18 x 0.41) CYLINDER BLOCK PLUG (.250-18 x .41) CYLINDER BLOCK |
4 | superseded |
| 2 | 48358 |
ПРОБКА (0.375) CYLINDER BLOCK PLUG (.375) CYLINDER BLOCK |
2 | superseded |
| 3 | 16951A1 |
КРАН В СБОРЕ CYLINDER BLOCK COCK ASSEMBLY CYLINDER BLOCK |
2 | superseded |
| 4 | 37478 |
ПРОБКА EXPANSION - CYLINDER BLOCK (1-3/4" DIA.) PLUG EXPANSION - CYLINDER BLOCK (1-3/4" DIA.) |
8 | superseded |
| 5 | 52190 |
ШТИФТ DOWEL - BLOCK TO HEAD PIN DOWEL - BLOCK TO HEAD |
4 | |
| 6 | 94140 |
КОМПЕНСАЦИОННАЯ ЗАГЛУШКА CAMSHAFT BEARING HOLE EXPANSION PLUG CAMSHAFT BEARING HOLE |
1 | |
| 7 | 85684 |
НАБОР ПОДШИПНИКОВ CAMSHAFT BEARING SET CAMSHAFT |
1 | |
| 8 | 72638 |
СЪЕМНИК HYDRAULIC VALVE - TAPPET LIFTER HYDRAULIC VALVE - TAPPET |
16 | disc. |
| 9 | 4734 |
РАСПРЕДЕЛИТЕЛЬНЫЙ ВАЛ CAMSHAFT |
1 |
