| # | Part Number | Description | Qty | Status |
|---|---|---|---|---|
| 1 | 87290A4 |
КОРПУС В СБОРЕ Thermostat HOUSING ASSEMBLY Thermostat |
1 | |
| 10 | 60410 |
ВИНТ (0.375-16 x 4.250) THERMOSTAT HOUSING TO INTAKE MANIFOLD SCREW (.375-16 x 4.250) THERMOSTAT HOUSING TO INTAKE MANIFOLD |
2 | |
| 11 | 35048 |
СТОПОРНАЯ ШАЙБА (0.375) THERMOSTAT HOUSING SCREW LOCKWASHER (.375) THERMOSTAT HOUSING SCREW |
2 | |
| 12 | 98477A2 |
КЛАПАН В СБОРЕ THERMOSTAT HOUSING VALVE ASSEMBLY THERMOSTAT HOUSING |
1 | |
| 13 | 3322070 |
РУКАВ (Общая длина 48.00") TEE TO EXHAUST ELBOWS HOSE (48.00 Inches Bulk) TEE TO EXHAUST ELBOWS |
2 | superseded |
| 13 | 969151 |
РУКАВ TEE TO EXHAUST ELBOWS (V-DRIVE) HOSE TEE TO EXHAUST ELBOWS (V-DRIVE) |
2 | disc. |
| 14 | 32780 |
ЗАЖИМ HOSE ATTACHING CLAMP HOSE ATTACHING |
8 | superseded |
| 15 | 88795 |
РУКАВ WATER PUMP TO OIL COOLER HOSE WATER PUMP TO OIL COOLER |
1 | |
| 15 | 93436 |
РУКАВ WATER PUMP TO OIL COOLER (V-DRIVE) HOSE WATER PUMP TO OIL COOLER (V-DRIVE) |
1 | disc. |
| 16 | 32780 |
ЗАЖИМ HOSE ATTACHING CLAMP HOSE ATTACHING |
4 | superseded |
| 17 | 88794 |
РУКАВ THERMOSTAT HOUSING TO OIL COOLER HOSE THERMOSTAT HOUSING TO OIL COOLER |
1 | |
| 18 | 47715 |
ЗАЖИМ HOSE ATTACHING CLIP HOSE ATTACHING |
1 | disc. |
| 19 | 87108 |
РУКАВ Литой THERMOSTAT HOUSING TO WATER PUMP HOSE Molded THERMOSTAT HOUSING TO WATER PUMP |
1 | superseded |
| 2 | 47511 |
РУКАВ THERMOSTAT HOUSING SLEEVE THERMOSTAT HOUSING |
1 | |
| 20 | 32781 |
ЗАЖИМ HOSE ATTACHING CLAMP HOSE ATTACHING |
2 | superseded |
| 21 | 87116 |
РУКАВ THERMOSTAT COVER TO EXHAUST MANIFOLD (Port) HOSE THERMOSTAT COVER TO EXHAUST MANIFOLD (Port) |
1 | superseded |
| 22 | 87117 |
РУКАВ THERMOSTAT COVER TO EXHAUST MANIFOLD (Starboard) HOSE THERMOSTAT COVER TO EXHAUST MANIFOLD (Starboard) |
1 | superseded |
| 3 | 32803 |
ПРОБКА Труба (0.375-18), латунь PLUG Pipe (.375-18) Brass |
2 | superseded |
| 4 | 53045 |
ПРОКЛАДКА THERMOSTAT HOUSING GASKET THERMOSTAT HOUSING |
1 | superseded |
| 5 | 59137 |
ТЕРМОСТАТ (140 градусов) (143 Degrees) THERMOSTAT (140 Degrees) (143 Degrees) |
1 | superseded |
| 6 | 47510 |
ПРОКЛАДКА THERMOSTAT GASKET THERMOSTAT |
1 | |
| 7 | 47508 |
РУКАВ THERMOSTAT SLEEVE THERMOSTAT |
1 | superseded |
| 8 | 41812 |
ПРОКЛАДКА THERMOSTAT COVER GASKET THERMOSTAT COVER |
1 | |
| 9 | 47441A1 |
КРЫШКА THERMOSTAT COVER THERMOSTAT |
1 |
