| # | Part Number | Description | Qty | Status |
|---|
| 1 |
8116661 |
SHOCK ROD ASSEMBLY
|
1 |
superseded
|
| 10 |
8116711 |
DRIVESHAFT
|
1 |
disc.
|
| 11 |
811626A3 |
SEAL KIT (With Case Bolts)
|
1 |
disc.
|
| 12 |
8116731 |
RESERVOIR KIT
|
1 |
disc.
|
| 13 |
813435 |
PLUG KIT
|
1 |
superseded
|
| 14 |
813442A2 |
MANUAL RELEASE ASSEMBLY
|
1 |
superseded
|
| 15 |
8116241 |
FRAME AND FIELD KIT
|
1 |
disc.
|
| 16 |
8116271 |
ARMATURE KIT
|
1 |
disc.
|
| 17 |
12665 |
SPRING KIT Brush Brush
|
1 |
disc.
|
| 18 |
811625 |
BRUSH CARD KIT
|
1 |
disc.
|
| 19 |
818898 |
PIN Anchor
|
1 |
|
| 2 |
813428 |
END CAP ASSEMBLY Trim Cylinder
|
1 |
disc.
|
| 20 |
821539 |
PIN Trilobe
|
1 |
|
| 21 |
996251 |
SHAFT
|
1 |
superseded
|
| 22 |
26419 |
NUT (#8-32) Brass
|
4 |
|
| 23 |
26992 |
LOCKWASHER (.250) Stainless Steel
|
4 |
|
| 24 |
64015 |
NUT (.250-20)
|
4 |
|
| 25 |
17201A2 |
CABLE ASSEMBLY (17.00 Inches) Trim
|
1 |
disc.
|
| 26 |
817626 |
SCREW (#10-16 x .380)
|
1 |
superseded
|
| 27 |
69205 |
C WASHER
|
1 |
superseded
|
| 28 |
22875 |
CLIP
|
1 |
|
| 29 |
818997A1 |
SOLENOID ASSEMBLY
|
2 |
superseded
|
| 3 |
813432A3 |
SEAL KIT Cylinder
|
1 |
disc.
|
| 30 |
818968 |
BUSHING
|
3 |
superseded
|
| 31 |
818967 |
GROMMET
|
3 |
|
| 32 |
19932100 |
SCREW (.250-20 x 1.00)
|
3 |
disc.
|
| 33 |
87379A14 |
WIRE ASSEMBLY (2.750 Inches)
|
1 |
disc.
|
| 33 |
87379A14 |
WIRE ASSEMBLY (2.750 Inches)
|
1 |
disc.
|
| 33 |
88807A16 |
CABLE ASSEMBLY (4.00 Inches) Black
|
2 |
|
| 34 |
97861 |
INSULATOR Solenoid
|
2 |
|
| 4 |
810776 |
PISTON KIT Memory
|
1 |
disc.
|
| 5 |
8116691 |
CYLINDER ASSEMBLY Trim
|
1 |
superseded
|
| 6 |
811678A5 |
SCREW AND SEAL KIT
|
1 |
superseded
|
| 7 |
8116707 |
PUMP/MANIFOLD KIT
|
1 |
disc.
|
| 8 |
823180A1 |
ROCKER ARM KIT
|
1 |
disc.
|
| 9 |
813436 |
SCREW KIT (4 Pieces)
|
1 |
disc.
|
| _ |
824051 |
PUMP ASSEMBLY Trim
|
1 |
superseded
|
