| # | Part Number | Description | Qty | Status |
|---|---|---|---|---|
| 1 | 806964A2 |
СТАРТЕР В СБОРЕ Колпачок диаметром 2-7/8 8 In. Starter Motor (PG260) STARTER MOTOR ASSEMBLY 2-7/8 Diameter End Cap 8 In. Starter Motor (PG260) |
1 | superseded |
| 1 | 812604A2 |
СТАРТЕР В СБОРЕ Колпачок диаметром 3-1/4 8 Inch Starter Motor (PG 200) STARTER MOTOR ASSEMBLY 3-1/4 Diameter End Cap 8 Inch Starter Motor (PG 200) |
1 | superseded |
| 1 | 12177A2 |
СТАРТЕР В СБОРЕ 12 Inch Starter Motor STARTER MOTOR ASSEMBLY 12 Inch Starter Motor |
1 | superseded |
| 1 | 76965A3 |
СТАРТЕР В СБОРЕ 12 Inch Starter Motor, L.H. Rotation STARTER MOTOR ASSEMBLY 12 Inch Starter Motor, L.H. Rotation |
1 | superseded |
| 1 | 79604A3 |
СТАРТЕР В СБОРЕ 12 Inch Starter Motor, R.H. Rotation STARTER MOTOR ASSEMBLY 12 Inch Starter Motor, R.H. Rotation |
1 | superseded |
| 10 | 96457 |
ШАЙБА Фенольный (0.27 x 0.81 x 0.062) (Mando #AR-150) (Motorola #8MR2039K) (Prestolite #8EM2003K4) WASHER Phenolic (.27 x .81 x .062) (Mando #AR-150) (Motorola #8MR2039K) (Prestolite #8EM2003K4) |
1 | |
| 10 | 96457 |
ШАЙБА Фенольный (0.27 x 0.81 x 0.062) (Mando #AC-155603) WASHER Phenolic (.27 x .81 x .062) (Mando #AC-155603) |
1 | |
| 11 | 26996 |
СТОПОРНАЯ ШАЙБА (№10), нержавеющая сталь (Mando #AC-155603) (Mando #AR-150) (Motorola #8MR2039K) (Prestolite #8EM2003K4) LOCKWASHER (#10) Stainless Steel (Mando #AC-155603) (Mando #AR-150) (Motorola #8MR2039K) (Prestolite #8EM2003K4) |
1 | |
| 12 | 79989 |
ГАЙКА (№10-24), нержавеющая сталь (Mando #AC-155603) (Mando #AR-150) (Motorola #8MR2039K) (Prestolite #8EM2003K4) NUT (#10-24) Stainless Steel (Mando #AC-155603) (Mando #AR-150) (Motorola #8MR2039K) (Prestolite #8EM2003K4) |
1 | |
| 13 | 21272 |
СТОПОРНАЯ ШАЙБА (0.250) (Mando #AR-150) (Motorola #8MR2039K) (Prestolite #8EM2003K4) LOCKWASHER (.250) (Mando #AR-150) (Motorola #8MR2039K) (Prestolite #8EM2003K4) |
1 | |
| 13 | 29245 |
ШАЙБА (0.281 x 0.500 x 0.060), нержавеющая сталь (Mando #AC-155603) WASHER (.281 x .500 x .060) Stainless Steel (Mando #AC-155603) |
1 | superseded |
| 14 | 64015 |
ГАЙКА (0.250-20) (Mando #AR-150) (Motorola #8MR2039K) (Prestolite #8EM2003K4) NUT (.250-20) (Mando #AR-150) (Motorola #8MR2039K) (Prestolite #8EM2003K4) |
1 | |
| 14 | 94330 |
ГАЙКА (0.250-20), латунь (Mando #AC-155603) NUT (.250-20) Brass (Mando #AC-155603) |
1 | |
| 14A | 5790811 |
РУКАВ (Общая длина 10.00") SLEEVE (10.00 Inches Bulk) |
2 | |
| 15 | 85013T |
СКОБА BRACE |
1 | |
| 16 | 26487 |
ВИНТ (0.375-16 x 1.12) SCREW (.375-16 x 1.12) |
1 | disc. |
| 17 | 35048 |
СТОПОРНАЯ ШАЙБА (0.375) LOCKWASHER (.375) |
1 | |
| 18 | 34714 |
ШАЙБА WASHER |
1 | |
| 19 | 74824 |
ВИНТ (0.312-18 x 1.250) SCREW (.312-18 x 1.250) |
1 | |
| 2 | 8053432 |
ВИНТ (0.375-16 x 4.33) 8 In. Starter Motor (PG260), 2 7/8 In. Diameter End Cap SCREW (.375-16 x 4.33) 8 In. Starter Motor (PG260), 2 7/8 In. Diameter End Cap |
2 | |
| 2 | 8053432 |
ВИНТ (0.375-16 x 4.33) 8 Inch Starter Motor (PG 200), 3-1/4 In. Diameter End Cap SCREW (.375-16 x 4.33) 8 Inch Starter Motor (PG 200), 3-1/4 In. Diameter End Cap |
2 | |
| 2 | 94435 |
БОЛТ (0.375-16 x 4.600) 12 Inch Starter Motor, L.H. Rotation BOLT (.375-16 x 4.600) 12 Inch Starter Motor, L.H. Rotation |
2 | superseded |
| 2 | 47462 |
ВИНТ (0.437-14 x 1.250) 12 Inch Starter Motor, R.H. Rotation SCREW (.437-14 x 1.250) 12 Inch Starter Motor, R.H. Rotation |
2 | |
| 20 | 26168 |
ШАЙБА WASHER |
1 | |
| 21 | 52095 |
ПРОСТАВКА SPACER |
1 | disc. |
| 22 | 93175T |
КРОНШТЕЙН BRACKET |
1 | disc. |
| 23 | 37612 |
ВИНТ (0.375-16 x 1.250) SCREW (.375-16 x 1.250) |
3 | |
| 24 | 35048 |
СТОПОРНАЯ ШАЙБА (0.375) LOCKWASHER (.375) |
3 | |
| 25 | 48308 |
ВИНТ (0.375-24 x 3.750) SCREW (.375-24 x 3.750) |
1 | |
| 26 | 20553 |
ШАЙБА (0.406 x 0.734 x 0.063) WASHER (.406 x .734 x .063) |
2 | |
| 27 | 33186 |
ВТУЛКА BUSHING |
1 | |
| 28 | 23161 |
ГАЙКА (.375-24) NUT (.375-24) |
1 | |
| 3 | 12404 |
СКОБА 12 Inch Starter Motor, L.H. Rotation BRACE 12 Inch Starter Motor, L.H. Rotation |
1 | disc. |
| 4 | 35765A1 |
ВИНТ И СТОПОРНАЯ ШАЙБА (0.312-18 x 0.625) 12 Inch Starter Motor, L.H. Rotation SCREW AND LOCKWASHER (.312-18 x .625) 12 Inch Starter Motor, L.H. Rotation |
1 | disc. |
| 5 | 29245 |
ШАЙБА (0.281 x 0.500 x 0.060), нержавеющая сталь 12 Inch Starter Motor, L.H. Rotation WASHER (.281 x .500 x .060) Stainless Steel 12 Inch Starter Motor, L.H. Rotation |
2 | superseded |
| 6 | 806949 |
ГАЙКА (M8-1.5) 8 In. Starter Motor (PG260), 2 7/8 In. Diameter End Cap NUT (M8-1.5) 8 In. Starter Motor (PG260), 2 7/8 In. Diameter End Cap |
1 | |
| 6 | 15874 |
ГАЙКА (M10) Use with 12 In. & 8 In. Starter Motor NUT (M10) Use with 12 In. & 8 In. Starter Motor |
1 | |
| 6 | 72008 |
ГАЙКА (0.250-20) Use with 12 In. & 8 In. Starter Motor NUT (.250-20) Use with 12 In. & 8 In. Starter Motor |
1 | superseded |
| 8 | 400211 |
ГАЙКА (M5), нержавеющая сталь 8 In. Starter Motor (PG260), 2 7/8 In. Diameter End Cap NUT (M5) Stainless Steel 8 In. Starter Motor (PG260), 2 7/8 In. Diameter End Cap |
1 | |
| 8 | 26419 |
ГАЙКА (№8-32), латунь Use with 12 In. & 8 In. Starter Motor NUT (#8-32) Brass Use with 12 In. & 8 In. Starter Motor |
1 | |
| 8 | 400211 |
ГАЙКА (M5), нержавеющая сталь Use with 12 In. & 8 In. Starter Motor NUT (M5) Stainless Steel Use with 12 In. & 8 In. Starter Motor |
1 | |
| 8A | 79695 |
ЧЕХОЛ Изолятор – черный Use with 12 In. & 8 In. Starter Motor BOOT Insulator - Black Use with 12 In. & 8 In. Starter Motor |
1 | superseded |
| 8A | 79695 |
ЧЕХОЛ Изолятор – черный 8 In. Starter Motor (PG260), 2 7/8 In. Diameter End Cap BOOT Insulator - Black 8 In. Starter Motor (PG260), 2 7/8 In. Diameter End Cap |
1 | superseded |
| 9 | 92497A3 |
ГЕНЕРАТОР В СБОРЕ (55 ампер) (Mando #AR-150) (Motorola #8MR2039K) (Prestolite #8EM2003K4) ALTERNATOR ASSEMBLY (55 Ampere) (Mando #AR-150) (Motorola #8MR2039K) (Prestolite #8EM2003K4) |
1 | superseded |
| 9 | 817119A4 |
ГЕНЕРАТОР (Mando #AC-155603) ALTERNATOR (Mando #AC-155603) |
1 |
