| # | Part Number | Description | Qty | Status |
|---|
| 1 |
95498M |
DECAL SIDE (ENGLISH)
|
1 |
superseded
|
| 1 |
95504M |
DECAL SIDE (FRENCH)
|
1 |
discontinued
|
| 10 |
30187 |
STEM BAYONET BODY
|
1 |
discontinued
|
| 11 |
20415 |
O-RING BAYONET BODY STEM
|
1 |
superseded
|
| 12 |
30189 |
SPRING BAYONET BAODY ASS'Y
|
1 |
|
| 13 |
30188 |
WASHER CAP
|
1 |
|
| 14 |
63187 |
FITTING Barb (.250-18) FUEL LINE
|
1 |
|
| 15 |
84955M |
HOSE CONNECTOR HOUSING TO BULB
|
1 |
superseded
|
| 16 |
81325M |
PRIMER BULB
|
1 |
superseded
|
| 17 |
82023M |
HOSE BULB TO ENGINE CONNECTOR
|
1 |
superseded
|
| 18 |
80752M |
CLAMP HOSE
|
4 |
superseded
|
| 19 |
81042M |
HOUSING ASSEMBLY ENGINE END
|
1 |
superseded
|
| 2 |
95489M |
DECAL TOP (ENGLISH)
|
1 |
discontinued
|
| 2 |
95503M |
DECAL TOP (FRENCH)
|
1 |
discontinued
|
| 20 |
82789M |
O-RING
|
1 |
discontinued
|
| 21 |
81327M |
COLLAR
|
1 |
discontinued
|
| 3 |
95490M |
CAP Fuel Tank
|
1 |
superseded
|
| 4 |
95499M |
METER ASSEMBLY Fuel
|
1 |
discontinued
|
| 5 |
95501M |
SEAL
|
4 |
discontinued
|
| 6 |
95502M |
SCREW
|
4 |
discontinued
|
| 7 |
95500M |
GASKET FUEL METER ASS'Y
|
1 |
discontinued
|
| 8 |
95216M |
LINE ASSEMBLY Fuel
|
1 |
superseded
|
| 9 |
30185A1 |
BAYONET BODY ASSEMBLY
|
1 |
superseded
|
