| # | Part Number | Description | Qty | Status |
|---|
| 1 |
9246M |
SWIVEL BRACKET [M-019911/ML-315401/E-252996/EL-554736] & Up
|
1 |
discontinued
|
| 1 |
8244M |
SWIVEL BRACKET [M-006086/ML-305361/E-251106/EL-552121] THRU [M-019910/ML-315400/E-252995/EL-554735]
|
1 |
superseded
|
| 10 |
81873M |
WASHER
|
1 |
discontinued
|
| 11 |
81964M |
BUSHING PIVOT SHAFT-UPPER
|
1 |
discontinued
|
| 12 |
81961M |
BUSHING PIVOT SHAFT-LOWER
|
1 |
discontinued
|
| 13 |
82274M |
O-RING PIVOT SHAFT BUSHING
|
1 |
discontinued
|
| 14 |
81959M |
BUSHING
|
1 |
discontinued
|
| 15 |
8245M |
BRACKET PORT
|
1 |
superseded
|
| 16 |
8246M |
BRACKET STARBOARD
|
1 |
discontinued
|
| 17 |
80048M |
HANDLE TRANSOM CLAMP SCREW
|
2 |
superseded
|
| 18 |
81756M |
SCREW TRANSOM CLAMP
|
2 |
discontinued
|
| 19 |
80638M |
PAD TRANSOM CLAMP SCREW
|
2 |
discontinued
|
| 2 |
91637M |
SEAL
|
1 |
discontinued
|
| 20 |
81888M |
PIN ROLL
|
2 |
discontinued
|
| 21 |
84835M |
SHAFT TILT STOP
|
1 |
discontinued
|
| 22 |
84836M |
KNOB TILT STOP SHAFT
|
1 |
superseded
|
| 23 |
82148M |
PIN ROLL
|
1 |
discontinued
|
| 24 |
91639M |
BOLT STEERING
|
1 |
discontinued
|
| 25 |
81836M |
WASHER
|
2 |
discontinued
|
| 26 |
81787M |
NUT
|
1 |
superseded
|
| 27 |
81388M |
CAP
|
2 |
superseded
|
| 28 |
82924M |
BOLT
|
1 |
discontinued
|
| 29 |
81979M |
SPACER CLAMP BRACKET
|
1 |
superseded
|
| 3 |
82369M |
FITTING GREASE
|
4 |
|
| 30 |
82392M |
NUT
|
1 |
superseded
|
| 31 |
91640M |
LEVER LOCK/RELEASE
|
1 |
discontinued
|
| 32 |
91641M |
COVER LEVER
|
1 |
discontinued
|
| 33 |
91642M |
SPRING TENSION
|
1 |
discontinued
|
| 34 |
91643M |
LINK REVERSE LOCK LEVER
|
1 |
discontinued
|
| 35 |
80648M |
CAM TILT
|
1 |
discontinued
|
| 36 |
91644M |
PIN
|
1 |
superseded
|
| 37 |
80645M |
ROD REVERSE LOCK LEVER
|
1 |
discontinued
|
| 38 |
84837M |
HOOK REVERSE LOCK-REAR
|
1 |
discontinued
|
| 39 |
80643M |
HOOK REVERSE LOCK-FRONT
|
1 |
discontinued
|
| 4 |
81439M |
CAP GREASE FITING
|
4 |
discontinued
|
| 40 |
81882M |
PIN
|
1 |
discontinued
|
| 41 |
82125M |
COTTER PIN
|
1 |
discontinued
|
| 42 |
82105M |
SPRING REVERSE LOCK
|
1 |
superseded
|
| 43 |
94569M |
PIN ASSEMBLY Tilt Lock
|
1 |
|
| 44 |
82857M |
PLATE Stopper
|
1 |
discontinued
|
| 45 |
82144M |
PIN ROLL
|
1 |
discontinued
|
| 46 |
82330M |
RING Snap
|
1 |
discontinued
|
| 47 |
82070M |
GROMMET
|
1 |
discontinued
|
| 5 |
80633M |
PLATE FRICTION
|
1 |
discontinued
|
| 6 |
96382M |
SCREW
|
1 |
discontinued
|
| 7 |
82217M |
WASHER
|
1 |
discontinued
|
| 8 |
84833M |
SHAFT STEERING PIVOT
|
1 |
discontinued
|
| 9 |
82368M |
PIN DOWEL
|
2 |
discontinued
|
