| # | Part Number | Description | Qty | Status |
|---|
| 0-1 |
92570M |
HANDLE ASSEMBLY Steering
|
1 |
superseded
|
| 1 |
81138M |
BRACKET STEERING
|
1 |
superseded
|
| 10 |
82204M |
WASHER THROTTLE SHAFT
|
1 |
superseded
|
| 11 |
82095M |
SPRING
|
1 |
discontinued
|
| 12 |
81945M |
BUSHING STEERING ARM
|
1 |
discontinued
|
| 13 |
41892M |
CABLE ASSEMBLY Throttle
|
2 |
discontinued
|
| 14 |
81747M |
BOLT CABLE
|
2 |
superseded
|
| 15 |
81765M |
NUT
|
4 |
discontinued
|
| 16 |
82064M |
GROMMET
|
1 |
discontinued
|
| 17 |
82119M |
SPACER
|
1 |
discontinued
|
| 18 |
81861M |
SPACER
|
1 |
discontinued
|
| 19 |
84850M |
WASHER
|
2 |
discontinued
|
| 2 |
84830M |
BOLT
|
4 |
discontinued
|
| 20 |
84851M |
WASHER WAVE
|
1 |
discontinued
|
| 21 |
84852M |
RETAINER
|
1 |
discontinued
|
| 22 |
84853M |
BOLT
|
1 |
superseded
|
| 23 |
84058M |
BOLT (M6 x 20)
|
1 |
|
| 24 |
82214M |
WASHER
|
2 |
discontinued
|
| 25 |
82895M |
FRICTION PIECE
|
OPT |
discontinued
|
| 26 |
83056M |
NUT
|
OPT |
discontinued
|
| 27 |
84058M |
BOLT (M6 x 20)
|
OPT |
|
| 3 |
84849M |
STEERIG HANDLE
|
1 |
superseded
|
| 4 |
81585M |
GRIP THROTTLE
|
1 |
discontinued
|
| 5 |
95497M |
HANDLE RUBBER [M-019911/ML-315401/E-252996/EL-554736] & Up
|
1 |
superseded
|
| 5 |
84854M |
RUBBER HANDLE [M-019910/ML-315400/E-252995/EL-554735] & Below
|
1 |
superseded
|
| 6 |
42432M |
INDICATOR THROTTLE [M-014871/ML-312186/E-252291/EL-553576] & Up
|
1 |
discontinued
|
| 6 |
97773M |
INDICATOR THROTTLE [M-009921/ML-308961/E-251701/EL-552686] THRU [M-014870/ML-312185/E-252290/EL-553575]
|
1 |
discontinued
|
| 6 |
92586M |
INDICATOR THROTTLE [M-009920/ML-308960/E-251700/EL-552685] & Below
|
1 |
superseded
|
| 7 |
81907M |
RIVET
|
1 |
discontinued
|
| 8 |
82483M |
SCREW
|
1 |
superseded
|
| 9 |
84856M |
LEVER THROTTLE
|
1 |
|
