| # | Part Number | Description | Qty | Status |
|---|
| - |
96586M |
POWERHEAD ASSEMBLY COMPLETE (SEE NOTE) [M-006086/ML-305361/E-251106/EL-552121] & Up
|
1 |
superseded
|
| - |
92574M |
POWERHEAD ASSEMBLY COMPLETE (SEE NOTE) [M-006085/ML-305360/E-251105/EL-552120] & Below
|
1 |
discontinued
|
| - |
92575M |
GASKET SET POWERHEAD
|
1 |
discontinued
|
| 1 |
8399M |
CRANKCASE ASSEMBLY [M-006086/ML-305361/E-251106/EL-552121] & Up
|
1 |
superseded
|
| 1 |
7871M |
CRANKCASE ASSEMBLY [M-006085/ML-305360/E-251105/EL-552120] & Below
|
1 |
discontinued
|
| 10 |
84732M |
ANODE
|
1 |
discontinued
|
| 11 |
82000M |
HOSE
|
1 |
superseded
|
| 12 |
82046M |
CLAMP HOSE
|
2 |
discontinued
|
| 13 |
81564M |
HOUSING OIL SEAL (UPPER)
|
1 |
discontinued
|
| 14 |
82245M |
SEAL Oil CRANKSHAFT (UPPER)
|
1 |
discontinued
|
| 15 |
81565M |
GASKET OIL SEAL HOUSING
|
1 |
discontinued
|
| 16 |
82199M |
WASHER LOCK
|
4 |
superseded
|
| 17 |
8400M |
HEAD CYLINDER
|
1 |
discontinued
|
| 18 |
81555M |
GASKET CYLINDER HEAD
|
1 |
superseded
|
| 19 |
41885M |
BOLT W/WASHER [M-009376/ML-308481/E-251701/EL-552631] & Up
|
11 |
discontinued
|
| 19 |
82407M |
BOLT [M-009375/ML-308480/E-251700/EL-552630] & Below
|
11 |
discontinued
|
| 2 |
80122M |
FITTING CRANKCASE DRAIN
|
1 |
discontinued
|
| 20 |
81098M |
THERMOSTAT
|
1 |
superseded
|
| 21 |
81030M |
COVER THERMOSTAT
|
1 |
discontinued
|
| 22 |
81031M |
GASKET THERMOSTAT COVER
|
1 |
superseded
|
| 23 |
81835M |
WASHER
|
1 |
|
| 24 |
83539M |
BOLT (M6 x 20)
|
3 |
superseded
|
| 25 |
81569M |
COVER EXHAUST-OUTER
|
1 |
discontinued
|
| 26 |
81568M |
COVER EXHAUST-INNER
|
1 |
|
| 27 |
81570M |
GASKET EXHAUST COVER
|
2 |
superseded
|
| 28 |
82453M |
BOLT [M-019911/ML-315401/E-252996/EL-554736] & Up
|
1 |
superseded
|
| 28 |
84239M |
BOLT [M-019910/ML-315400/E-252995/EL-554735] & Below
|
1 |
superseded
|
| 29 |
96293M |
BOLT [M-009376/ML-308481/E-251701/EL-552631] & Up
|
4 |
superseded
|
| 29 |
84488M |
BOLT [M-009375/ML-308480/E-251700/EL-552630] & Below
|
4 |
superseded
|
| 3 |
80727M |
CHECK VALVE ASSEMBLY
|
1 |
discontinued
|
| 30 |
92523M |
BOLT
|
6 |
superseded
|
| 31 |
82371M |
SPARK PLUG B-7HS (NGK)
|
2 |
superseded
|
| 32 |
82197M |
WASHER [M-019911/ML-315401/E-252996/EL-554736] & Below
|
3 |
superseded
|
| 4 |
80107M |
VALVE CHECK
|
1 |
discontinued
|
| 5 |
41885M |
BOLT W/WASHER [M-009376/ML-308481/E-251701/EL-552631] & Up
|
2 |
discontinued
|
| 5 |
82406M |
BOLT W/WASHER [M-009375/ML-308480/E-251700/EL-552630] & Below
|
2 |
discontinued
|
| 6 |
41884M |
BOLT (M8 x 55) W/WASHER [M-009376/ML-308481/E-251701/EL-552631] & Up
|
8 |
superseded
|
| 6 |
82408M |
BOLT [M-009375/ML-308480/E-251700/EL-552630] & Below
|
8 |
discontinued
|
| 7 |
80564M |
WASHER [M-009375/ML-308480/E-251700/EL-552630] & Below
|
21 |
discontinued
|
| 8 |
95209M |
SCREW [M-019911/ML-315401/E-252996/EL-554736] & Up
|
1 |
discontinued
|
| 8 |
82167M |
SCREW [M-019910/ML-315400/E-252995/EL-554735] & Below
|
1 |
superseded
|
| 9 |
82364M |
PIN Dowel
|
2 |
discontinued
|
