| # | Part Number | Description | Qty | Status |
|---|
| - |
92575M |
GASKET SET POWERHEAD
|
1 |
discontinued
|
| - |
84773M |
REPAIR KIT Carburetor
|
1 |
superseded
|
| 1 |
92576M |
COVER AIR INTAKE (INNER)
|
1 |
discontinued
|
| 10 |
82405M |
BOLT
|
2 |
discontinued
|
| 11 |
83285M |
BOLT
|
7 |
discontinued
|
| 12 |
82199M |
WASHER LOCK
|
9 |
superseded
|
| 13 |
82380M |
NUT
|
2 |
superseded
|
| 14 |
82199M |
WASHER
|
2 |
superseded
|
| 15 |
84758M |
REED VALVE ASSEMBLY
|
1 |
superseded
|
| 16 |
84759M |
REED SET (REED STOPS NOT INCLUDED)
|
1 |
discontinued
|
| 17 |
80572M |
GASKET CARBURETOR MANIFOLD
|
1 |
superseded
|
| 18 |
83960M |
KNOB CHOKE
|
1 |
discontinued
|
| 19 |
84760M |
GROMMET CHOKE KNOB
|
1 |
discontinued
|
| 2 |
92577M |
COVER AIR INTAKE (OUTER)
|
1 |
discontinued
|
| 20 |
84761M |
LEVER CHOKE
|
1 |
discontinued
|
| 21 |
84762M |
PIN ROLL
|
1 |
discontinued
|
| 22 |
92579M |
ROD CHOKE
|
1 |
discontinued
|
| 23 |
81191M |
BRACKET
|
1 |
superseded
|
| 24 |
82034M |
CLAMP HOSE
|
1 |
superseded
|
| 3 |
92578M |
GASKET COVER
|
1 |
superseded
|
| 4 |
84245M |
SCREW
|
2 |
superseded
|
| 5 |
82196M |
WASHER
|
2 |
superseded
|
| 6 |
80570M |
MANIFOLD INTAKE
|
1 |
superseded
|
| 7 |
91735M |
STUD CARBURETOR ATTACHING
|
2 |
discontinued
|
| 8 |
80569M |
GASKET INTAKE MANIFOLD
|
1 |
discontinued
|
| 9 |
80571M |
GASKET REED VALVE
|
1 |
discontinued
|
