| # | Part Number | Description | Qty | Status |
|---|
| 1 |
82490M |
SCREW BASE ATTACHING
|
3 |
superseded
|
| 10 |
81582M |
LINK ROD MAGNETO CONTROL
|
1 |
discontinued
|
| 11 |
80629M |
SWIVEL LINK ROD
|
1 |
discontinued
|
| 12 |
81789M |
WASHER
|
1 |
discontinued
|
| 13 |
82378M |
NUT
|
3 |
superseded
|
| 14 |
91651M |
LEVER THROTTLE SHAFT [M-009376/ML-308481/E-251701/EL-552631] & Up
|
1 |
discontinued
|
| 14 |
92589M |
LEVER THROTTLE SHAFT [M-009375/ML-308480/E-251700/EL-552630] & Below
|
1 |
discontinued
|
| 15 |
81134M |
SHAFT THROTTLE
|
1 |
discontinued
|
| 16 |
81946M |
BUSHING
|
2 |
discontinued
|
| 17 |
82156M |
PIN ROLL
|
1 |
discontinued
|
| 18 |
81722M |
LINK ROD
|
1 |
discontinued
|
| 19 |
83539M |
BOLT (M6 x 20)
|
4 |
superseded
|
| 2 |
82196M |
WASHER
|
3 |
superseded
|
| 20 |
82199M |
WASHER [M-019910/ML-315400/E-252995/EL-554735] & Below
|
4 |
superseded
|
| 21 |
96378M |
STOP MAGNETO BASE [M-006086/ML-305361/E-251106/EL-552121] & Up
|
1 |
discontinued
|
| 21 |
80628M |
STOP MAGNETO BASE [M-006085/ML-305360/E-251105/EL-552120] & Below
|
1 |
discontinued
|
| 22 |
83539M |
BOLT (M6 x 20)
|
4 |
superseded
|
| 23 |
82380M |
NUT
|
2 |
superseded
|
| 24 |
82199M |
WASHER
|
4 |
superseded
|
| 25 |
92572M |
PLATE FRICTION
|
1 |
discontinued
|
| 26 |
92573M |
RETAINER MAGNETO BASE (UPPER)
|
1 |
discontinued
|
| 27 |
96379M |
RETAINER MAGNETO BASE [M-019911/ML-315401/E-252996/EL-554736] & Up
|
1 |
discontinued
|
| 27 |
83199M |
RETAINER MAGNETO BASE [M-019910/ML-315400/E-252995/EL-554735] & Below
|
1 |
discontinued
|
| 3 |
81581M |
CAM MAGNETO CONTROL
|
1 |
superseded
|
| 4 |
83310M |
COLLAR
|
1 |
discontinued
|
| 5 |
81969M |
WASHER
|
1 |
discontinued
|
| 6 |
82405M |
BOLT
|
1 |
discontinued
|
| 7 |
81563M |
BRACKET THROTTLE CABLE
|
1 |
discontinued
|
| 8 |
84303M |
BOLT
|
1 |
superseded
|
| 9 |
81225M |
END
|
3 |
superseded
|
