| # | Part Number | Description | Qty | Status |
|---|
| 1 |
96356M |
SOLENOID ASSEMBLY Starter
|
1 |
superseded
|
| 10 |
84937M |
FUSE ASSEMBLY
|
1 |
discontinued
|
| 11 |
81522M |
FUSE
|
1 |
discontinued
|
| 12 |
97684M |
SWITCH ASSEMBLY Neutral Start
|
1 |
discontinued
|
| 13 |
81110M |
PLATE SWITCH AND LOCKOUT MOUNTING
|
1 |
discontinued
|
| 14 |
84940M |
SOLENOID Choke
|
1 |
discontinued
|
| 15 |
84411M |
HOOK WIRE
|
1 |
discontinued
|
| 16 |
82145M |
PIN ROLL
|
1 |
discontinued
|
| 17 |
81667M |
WIRE PULL
|
1 |
discontinued
|
| 18 |
84941M |
PLATE SOLENOID MOUNTING
|
1 |
discontinued
|
| 19 |
82060M |
GROMMET
|
1 |
discontinued
|
| 2 |
96357M |
SOLENOID
|
1 |
superseded
|
| 20 |
82512M |
SCREW
|
4 |
discontinued
|
| 21 |
82799M |
WASHER
|
4 |
superseded
|
| 22 |
84655M |
SCREW
|
2 |
superseded
|
| 23 |
82196M |
WASHER
|
2 |
superseded
|
| 24 |
82258M |
O-RING
|
1 |
|
| 25 |
84303M |
BOLT
|
1 |
superseded
|
| 26 |
82199M |
WASHER LOCK
|
1 |
superseded
|
| 27 |
97681M |
PANEL ASSEMBLY Switch [M-009376/ML-308481/E-251701/EL-552631] & Up
|
1 |
superseded
|
| 27 |
97769M |
PANEL ASSEMBLY Switch [M-006086/ML-305361/E-251106/EL-552121] THRU [M-009375/ML-308480/E-251700/EL-552630]
|
1 |
discontinued
|
| 27 |
92604M |
SWITCH PANEL [M-006085/ML-305360/E-251105/EL-552120] & Below
|
1 |
discontinued
|
| 28 |
84943M |
KEY SWITCH [M-006086/ML-305361/E-251106/EL-552121] & Up
|
1 |
superseded
|
| 28 |
92605M |
MAIN SWITCH [M-006085/ML-305360/E-251105/EL-552120] & Below
|
1 |
discontinued
|
| 29 |
84944M |
SWITCH Choke
|
1 |
discontinued
|
| 3 |
84934M |
BRACKET
|
1 |
discontinued
|
| 30 |
97682M |
SWITCH ASSEMBLY Stop
|
1 |
discontinued
|
| 31 |
97756M |
STOPPER
|
1 |
|
| 32 |
42435M |
PANEL [M-019911/ML-315401/E-252996/EL-554736] & Up
|
1 |
discontinued
|
| 32 |
92661M |
SWITCH PANEL [M-019910/ML-315400/E-252995/EL-554735] & Below
|
1 |
discontinued
|
| 33 |
81537M |
BRACKET
|
1 |
discontinued
|
| 34 |
82487M |
SCREW
|
1 |
superseded
|
| 35 |
82184M |
LOCKWASHER
|
1 |
superseded
|
| 36 |
80164M |
SCREW [M-019911/ML-315401/E-252996/EL-554736] & Up
|
4 |
discontinued
|
| 36 |
84946M |
SCREW [M-019910/ML-315400/E-252995/EL-554735] & Below
|
4 |
discontinued
|
| 37 |
82377M |
NUT [M-019911/ML-315401/E-252996/EL-554736] & Up
|
4 |
discontinued
|
| 37 |
82378M |
NUT [M-019910/ML-315400/E-252995/EL-554735] & Below
|
4 |
superseded
|
| 38 |
82193M |
WASHER LOCK
|
4 |
superseded
|
| 39 |
82799M |
WASHER [M-019911/ML-315401/E-252996/EL-554736] & Up
|
4 |
superseded
|
| 39 |
82196M |
WASHER [M-019910/ML-315400/E-252995/EL-554735] & Below
|
4 |
superseded
|
| 4 |
92601M |
PLATE SOLENOID MOUNTING
|
1 |
discontinued
|
| 40 |
97770M |
HARNESS ASSEMBLY Engine Wiring [E-251701/EL-552631] & Up
|
1 |
superseded
|
| 40 |
96354M |
HARNESS ASSEMBLY Engine Wiring [E-251700/EL-552630] & Below
|
1 |
discontinued
|
| 41 |
97771M |
WIRE ASSEMBLY BATTERY [E-251701/EL-552631] & Up
|
1 |
discontinued
|
| 41 |
96355M |
WIRE ASSEMBLY BATTERY [E-251700/EL-552630] & Below
|
1 |
discontinued
|
| 42 |
84949M |
WIRE ASSEMBLY [E-251106/EL-552121] & Up
|
1 |
superseded
|
| 42 |
92607M |
WIRE ASSEMBLY Ignition [E-251105/EL-552120] & Below
|
1 |
superseded
|
| 43 |
84950M |
GROMMET
|
1 |
discontinued
|
| 44 |
82066M |
GROMMET
|
1 |
discontinued
|
| 45 |
84711M |
EXTENSION WIRE HARNESS (5M)
|
1 |
discontinued
|
| 46 |
84707M |
CLAMP [E-251701/EL-552631] & Up
|
1 |
superseded
|
| 46 |
97772M |
CLAMP [E-251700/EL-552630] & Below
|
1 |
discontinued
|
| 47 |
84708M |
PLATE
|
1 |
discontinued
|
| 48 |
84709M |
SCREW
|
1 |
discontinued
|
| 49 |
84876M |
GROMMET
|
3 |
discontinued
|
| 5 |
96358M |
WIRE SOLENOID [E-251106/EL-552121] & Up
|
1 |
discontinued
|
| 5 |
92602M |
WIRE SOLENOID [E-251105/EL-552120] & Below
|
1 |
discontinued
|
| 6 |
81652M |
RECTIFIER
|
1 |
superseded
|
| 7 |
82492M |
SCREW
|
1 |
superseded
|
| 8 |
82196M |
WASHER
|
1 |
superseded
|
| 9 |
92603M |
PLATE RECTIFIER MOUNTING
|
1 |
discontinued
|
