| # | Part Number | Description | Qty | Status |
|---|
| 1 |
8371M |
CDI MAGNETO ASSEMBLY (MANUAL)
|
1 |
discontinued
|
| 1 |
8370M |
CDI MAGNETO ASSEMBLY (ELECTRIC)
|
1 |
discontinued
|
| 10 |
97803M |
SCREW W/WASHER [M-019911/ML-315401/E-252996/EL-554736] & Up
|
2 |
discontinued
|
| 10 |
96346M |
SCREW W/WASHER [M-006086/ML-305361/E-251106/EL-552121] THRU [M-019910/ML-315400/E-252995/EL-554735]
|
2 |
discontinued
|
| 11 |
91699M |
SCREW W/WASHER (MANUAL)
|
1 |
discontinued
|
| 12 |
91693M |
SCREW W/WASHER (ELECTRIC)
|
1 |
discontinued
|
| 13 |
80689M |
COVER
|
1 |
superseded
|
| 14 |
84303M |
BOLT
|
3 |
superseded
|
| 15 |
82198M |
WASHER
|
3 |
superseded
|
| 16 |
81770M |
NUT
|
1 |
discontinued
|
| 17 |
81814M |
WASHER
|
1 |
discontinued
|
| 18 |
99951M |
STOP MAGNETO BASE [M-009376/ML-308481/E-251701/EL-552631] & Up
|
1 |
discontinued
|
| 18 |
83305M |
STOP MAGNETO BASE [M-009375/ML-308480/E-251700/EL-552630] & Below
|
1 |
superseded
|
| 19 |
84303M |
BOLT
|
2 |
superseded
|
| 2 |
8372M |
FLYWHEEL ASSEMBLY (MANUAL)
|
1 |
discontinued
|
| 2 |
8369M |
FLYWHEEL ASSEMBLY (ELECTRIC)
|
1 |
superseded
|
| 20 |
82198M |
WASHER
|
2 |
superseded
|
| 21 |
92591M |
CAM
|
1 |
discontinued
|
| 22 |
84313M |
BOLT
|
2 |
discontinued
|
| 23 |
82196M |
WASHER
|
2 |
superseded
|
| 24 |
96348M |
CLAMP
|
1 |
discontinued
|
| 25 |
84315M |
BOLT
|
1 |
superseded
|
| 26 |
96349M |
BRACKET
|
1 |
discontinued
|
| 27 |
84869M |
DAMPER
|
1 |
discontinued
|
| 28 |
81523M |
DAMPER
|
3 |
discontinued
|
| 29 |
82851M |
BUSHING
|
3 |
superseded
|
| 3 |
96342M |
BASE ASSEMBLY
|
1 |
discontinued
|
| 30 |
82405M |
BOLT
|
3 |
discontinued
|
| 31 |
82979M |
WASHER
|
3 |
superseded
|
| 32 |
84870M |
STUD
|
1 |
discontinued
|
| 33 |
82380M |
NUT
|
2 |
superseded
|
| 34 |
82199M |
WASHER
|
2 |
superseded
|
| 35 |
84871M |
WIRE GROUND
|
1 |
discontinued
|
| 36 |
84303M |
BOLT
|
2 |
superseded
|
| 37 |
82197M |
WASHER
|
2 |
superseded
|
| 38 |
43077M |
SWITCHBOX ASSEMBLY
|
1 |
superseded
|
| 39 |
84873M |
BRACKET
|
1 |
discontinued
|
| 4 |
96343M |
BASE MAGNETO
|
1 |
discontinued
|
| 40 |
82405M |
BOLT
|
2 |
discontinued
|
| 41 |
82199M |
WASHER
|
2 |
superseded
|
| 42 |
96351M |
COIL ASSEMBLY Ignition
|
1 |
superseded
|
| 43 |
82069M |
GROMMET
|
2 |
discontinued
|
| 44 |
82405M |
BOLT
|
2 |
discontinued
|
| 45 |
80935M |
PROTECTER (NOISE SUPPRESSOR)
|
2 |
superseded
|
| 45 |
82788M |
CAP ASSEMBLY Spark Plug
|
OPT |
superseded
|
| 46 |
96352M |
CLAMP
|
1 |
discontinued
|
| 47 |
84876M |
GROMMET
|
1 |
discontinued
|
| 48 |
96353M |
CLAMP
|
1 |
discontinued
|
| 49 |
99952M |
CLAMP [M-009376/ML-308481/E-251701/EL-552631] & Up
|
1 |
discontinued
|
| 5 |
96344M |
COIL ASSEMBLY Charge
|
1 |
discontinued
|
| 6 |
96345M |
COIL ASSEMBLY Pulser
|
1 |
discontinued
|
| 7 |
96346M |
SCREW W/WASHER
|
2 |
discontinued
|
| 8 |
91691M |
SCREW W/WASHER
|
1 |
discontinued
|
| 9 |
94804M |
COIL ASSEMBLY Lighting
|
1 |
discontinued
|
