| # | Part Number | Description | Qty | Status |
|---|
| 1 |
MVP05301 |
COVER Top - Black
|
1 |
superseded
|
| 10 |
M879316T |
COLUMN (30.00 Inches) Black Composite
|
1 |
disc.
|
| 10 |
MVP04902T |
COLUMN (48.00 Inches) Black Composite
|
1 |
superseded
|
| 10 |
MVP04903T |
COLUMN (54.00 Inches) Black Composite
|
1 |
superseded
|
| 10 |
MVP04904T |
COLUMN (60.00 Inches) Black Composite
|
1 |
superseded
|
| 10 |
M879257T |
COLUMN (70.00 Inches) Black Composite
|
1 |
disc.
|
| 11 |
MVP158012 |
COLLAR ASSEMBLY Depth - Design I - No Lip On Bottom
|
1 |
superseded
|
| 11 |
M899552T1 |
COLLAR ASSEMBLY Depth - Design II - With Outer Lip On Bottom
|
1 |
|
| 12 |
MFK02101T |
BUSHING Nyliner (.375)
|
2 |
superseded
|
| 13 |
M899757T |
FERRITE RING - 24 Volt Models
|
2 |
superseded
|
| 14 |
MVP01901T |
GROMMET Steering Cable
|
1 |
|
| 15 |
MVP40001T |
TRANSMISSION ASSEMBLY Black Service Complete - Design I - Lever Handle With Mount Pin
|
1 |
superseded
|
| 15 |
M879306T |
TRANSMISSION ASSEMBLY Black Service Complete - Design II - Lever Handle Without Mount Pin
|
1 |
disc.
|
| 16 |
NSS |
NOT SOLD SEPARATE Column Drive Tube - Design I And Design II
|
1 |
|
| 17 |
MVP20001 |
LEVER HANDLE Black - Design I - Used With Mount Pin
|
1 |
superseded
|
| 17 |
M899551T1 |
LEVER HANDLE Black - Design II - Used Without Mount Pin
|
1 |
disc.
|
| 18 |
MR22602T |
WASHER (.390 x .630 x .022) Nylon - Design I And Design II
|
2 |
disc.
|
| 19 |
MBK04601 |
E RING - Design I
|
4 |
superseded
|
| 19 |
MBK04601 |
E RING - Design II
|
2 |
superseded
|
| 2 |
M899667T |
DECAL Top Cover - MotorGuide W45 12 Volt Wireless
|
1 |
disc.
|
| 2 |
M899668T |
DECAL Top Cover - MotorGuide W55 12 Volt Wireless
|
1 |
disc.
|
| 2 |
M899669T |
DECAL Top Cover - MotorGuide W75 24 Volt Wireless
|
1 |
disc.
|
| 20 |
MVP17102T |
SPRING Left Hand - Black - Design I And Design II
|
1 |
disc.
|
| 21 |
MVP17103T |
SPRING Right Hand - Black - Design I And Design II
|
1 |
disc.
|
| 22 |
MVP10601T |
PIN Latch/Lever Handle - Design I And Design II
|
1 |
disc.
|
| 23 |
MVP10605T |
PIN Lever Handle/Mount - Design I
|
1 |
disc.
|
| 24 |
MBV39701T |
LOWER UNIT ASSEMBLY Complete (45# - Variable) Marked MBV397012 - 12 Volt FW45 Models - NOTE: See Lower Unit Assembly Section For Service Parts Breakdown
|
1 |
disc.
|
| 24 |
MCV39701T |
LOWER UNIT ASSEMBLY Complete (55# - Variable) Marked MCV397012 - 12 Volt FW55 Models - NOTE: See Lower Unit Assembly Section For Service Parts Breakdown
|
1 |
superseded
|
| 24 |
MSV39701T |
LOWER UNIT ASSEMBLY Complete (75# - Variable) Marked MSV397012 - 24 Volt FW75 - 48/54/60 Inch Models - NOTE: See Lower Unit Assembly Section For Service Parts Breakdown
|
1 |
superseded
|
| 24 |
M879256T |
LOWER UNIT ASSEMBLY Complete (75# - Variable) Marked 8M4001012 - 24 Volt FW75 - 70 Inch Models - NOTE: See Lower Unit Assembly Section For Service Parts Breakdown
|
1 |
disc.
|
| 25 |
MAR17501 |
WASHER (.385 x .885 x .095) Nylon
|
1 |
superseded
|
| 26 |
MVP12401T |
PROP KIT 2 Blade Nylon - 3.5 Inch
|
1 |
disc.
|
| 27 |
MAR09902 |
PROP NUT
|
1 |
superseded
|
| 28 |
MBR10202 |
PIN Prop Drive (.156 x 1.00)
|
1 |
superseded
|
| 29 |
8M0119628 |
HYSOL EPOXY ADHESIVE 50ml
|
1 |
|
| 3 |
MVP00401 |
COVER Bottom - Black - NOTE: Design I - Use With Acorn Nut MVP09801T
|
1 |
superseded
|
| 3 |
8M4000582 |
COVER KIT Bottom - Black Includes Screw And Lock Nut - NOTE: Design II - Use With Lock Nut 11-MXT09802
|
1 |
|
| 4 |
MVP13401T |
SCREW (.250-20 x 2.00) Stainless Steel
|
1 |
disc.
|
| 5 |
MVP09801T |
NUT Acorn (.250-20) Stainless Steel - NOTE: Design I - Used With Bottom Cover MVP00401
|
1 |
disc.
|
| 5 |
MXT09802 |
LOCKNUT (.250-20) Stainless Steel - NOTE: Design II - Used With Bottom Cover 8M4000582
|
1 |
superseded
|
| 6 |
MAT14101 |
SCREW (#8 x .625) Stainless Steel
|
6 |
superseded
|
| 7 |
MBF02901 |
CONNECTOR Pigtail (#18-8)
|
2 |
superseded
|
| 8 |
MVP32801 |
CABLE ASSEMBLY Coiled
|
1 |
superseded
|
| 9 |
MVP13301T |
SCREW (#10-24 x .750) Stainless Steel
|
2 |
disc.
|
