| # | Part Number | Description | Qty | Status |
|---|
| - |
895287A02 |
WATER TEMPERATURE GAUGE KIT (60-200 F) Black Face, Blue/White Graduations, Black Bezel
|
1 |
disc.
|
| - |
895287A22 |
WATER TEMPERATURE GAUGE KIT (60-200 F) White Face, Black Graduations, White Bezel
|
1 |
disc.
|
| - |
895287A42 |
WATER TEMPERATURE GAUGE KIT (60-200 F) White Face, Black Graduations, Chrome Bezel
|
1 |
disc.
|
| - |
895287Q02 |
WATER TEMPERATURE GAUGE KIT (100-220 F) Black Face, White/Red Graduations, Black Bezel
|
1 |
disc.
|
| - |
895287Q22 |
WATER TEMPERATURE GAUGE KIT (60-220 F) White Face, Black Graduations, Black Bezel
|
1 |
disc.
|
| - |
895287Q42 |
WATER TEMPERATURE GAUGE KIT (60-200 F) Black Face, Orange/White Graduations, Black Bezel
|
1 |
disc.
|
| - |
895287Q62 |
WATER TEMPERATURE GAUGE KIT (60-220 F) Black Face, Red/White Graduations, Chrome Bezel
|
1 |
disc.
|
| 1 |
NSS |
NOT SOLD SEPARATE Gauge Only
|
1 |
|
| 10 |
851776 |
TERMINAL Female
|
1 |
disc.
|
| 11 |
896437A01 |
CABLE ASSEMBLY Black
|
1 |
disc.
|
| 12 |
896437A03 |
CABLE ASSEMBLY Purple
|
1 |
disc.
|
| 13 |
12415 |
SENDER Temperature (Must be ordered separately)
|
1 |
|
| 14 |
86306A01 |
ADAPTER (Must be ordered separately)
|
1 |
disc.
|
| 2 |
898139 |
SOCKET Black (2 Walt)
|
1 |
|
| 3 |
898139001 |
SOCKET AND BULB (Black / 2 Watt Bulb)
|
1 |
|
| 4 |
896437008 |
BRACKET
|
1 |
disc.
|
| 5 |
26419 |
NUT (#8-32) Brass
|
4 |
|
| 6 |
23836 |
LOCKWASHER
|
4 |
disc.
|
| 7 |
896437A09 |
CABLE ASSEMBLY Tan - With Sleeve
|
1 |
disc.
|
| 8 |
896437A06 |
CABLE ASSEMBLY Tan
|
1 |
disc.
|
| 9 |
816311T |
TIE STRAP (8.00 Inches)
|
5 |
|
