| # | Part Number | Description | Qty | Status |
|---|
| 1 |
8M0022552 |
BRACKET
|
1 |
superseded
|
| 10 |
4010516 |
SCREW (M5 x 16) Stainless Steel
|
2 |
|
| 11 |
8M0100517 |
MERCATHODE CONTROLLER MerCathode
|
1 |
|
| 12 |
90271 |
SCREW (.375-16 x .62)
|
2 |
|
| 13 |
8M0007709 |
BRACKET
|
1 |
superseded
|
| 14 |
4008930 |
SCREW (M8 x 30) Stainless Steel
|
1 |
|
| 15 |
824013 |
BUSHING
|
1 |
|
| 16 |
8M0007717 |
BRACKET
|
1 |
|
| 17 |
82104510 |
SCREW (M5 x 10)
|
2 |
|
| 18 |
24836 |
CLIP
|
2 |
|
| 19 |
68219 |
NUT (#10-32) Stainless Steel
|
4 |
|
| 2 |
889664 |
NUT (1.500-18) Black Nylon
|
1 |
|
| 20 |
65292 |
J CLIP
|
1 |
superseded
|
| 21 |
816311T |
TIE STRAP (8.00 Inches)
|
4 |
|
| 22 |
882751A1 |
RELAY ASSEMBLY
|
1 |
superseded
|
| 23 |
828102 |
BRACKET
|
3 |
superseded
|
| 24 |
818967 |
GROMMET
|
1 |
|
| 25 |
898968 |
PLATE (With Screws)
|
3 |
|
| 26 |
882751 |
RELAY
|
2 |
superseded
|
| 27 |
822179 |
GROMMET
|
1 |
|
| 3 |
8M2001655 |
NUT
|
1 |
|
| 4 |
879148T46 |
TVM MODULE (Port)
|
1 |
superseded
|
| 4 |
879148T56 |
TVM MODULE (Starboard)
|
1 |
superseded
|
| 5 |
82130025 |
SCREW (M6 x 25)
|
3 |
|
| 6 |
65567 |
WASHER (.265 x .750 x .048) Stainless Steel
|
3 |
|
| 7 |
834985 |
GROMMET
|
3 |
superseded
|
| 8 |
856954 |
BUSHING
|
3 |
|
| 9 |
82130025 |
SCREW (M6 x 25)
|
3 |
|
