| # | Part Number | Description | Qty | Status |
|---|
| - |
889424A1 |
SEAL/GASKET SET Jet Drive Housing - NOTE: See Seal/Gasket Set - Jet Drive Housing Section For Parts Breakdown
|
1 |
|
| - |
878228A2 |
HOUSING ASSEMBLY Jet Drive - Complete - NOTE: No Impeller
|
1 |
disc.
|
| 1 |
878228A2 |
HOUSING ASSEMBLY Jet Drive - Complete - NOTE: No Impeller
|
1 |
disc.
|
| 1 |
859438A5 |
HOUSING ASSEMBLY Basic Jet Drive
|
1 |
|
| 10 |
32509 |
O-RING (.489 x .070)
|
1 |
|
| 11 |
21836 |
O-RING (.796 x .139)
|
1 |
superseded
|
| 12 |
859774 |
O-RING (.412 x .210)
|
1 |
|
| 13 |
879634 |
GROMMET Pump Mount
|
1 |
|
| 14 |
826292 |
NUT (M10) Brass/Nickel Plated
|
10 |
|
| 15 |
859567 |
TUBE Water
|
1 |
|
| 16 |
401388 |
NUT (M8) Stainless Steel
|
2 |
|
| 17 |
46765 |
WASHER (.390 x 1.50 x .120)
|
2 |
|
| 18 |
877799 |
WASHER (.900 x 1.50 x .125)
|
2 |
|
| 19 |
853905T |
PLATE Trim
|
1 |
|
| 2 |
63186 |
FITTING (.125-27) Siphon Drain Hose
|
1 |
disc.
|
| 20 |
850047 |
SCREW (M8 x 35)
|
2 |
|
| 21 |
883795A2 |
RIDE PLATE KIT
|
1 |
|
| 22 |
832838 |
SCREW (M6 x 20) With Nylon Patch
|
16 |
superseded
|
| 23 |
859441A1 |
SEAL KIT Ride Plate
|
1 |
|
| 24 |
856627T3 |
HYDRO SURGE GRATE KIT Aluminum - Automatic Weed Cleaning
|
1 |
|
| 25 |
856628T |
SPRING Inlet Grate
|
1 |
|
| 26 |
885588T |
TINES Inlet Grate
|
1 |
|
| 27 |
856627T |
FRAME Inlet Grate
|
1 |
|
| 28 |
832838 |
SCREW (M6 x 20) With Nylon Patch
|
2 |
superseded
|
| 29 |
856732 |
SCREW Special Pivot
|
2 |
disc.
|
| 3 |
820640 |
STUD (M10 x 55)
|
10 |
|
| 30 |
4010725 |
SCREW (M8 x 25)
|
2 |
|
| 31 |
852962T |
SCREEN Inlet - 6 Tines - Aluminum
|
OPT |
|
| 32 |
832838 |
SCREW (M6 x 20) With Nylon Patch
|
2 |
superseded
|
| 33 |
4010725 |
SCREW (M8 x 25)
|
2 |
|
| 34 |
854810T1 |
GRATE KIT Rock Inlet 12 Tines - Stainless Steel - For Shallow Rocky Conditions
|
OPT |
|
| 35 |
832838 |
SCREW (M6 x 20) With Nylon Patch
|
2 |
superseded
|
| 36 |
4010725 |
SCREW (M8 x 25)
|
2 |
|
| 37 |
826292 |
NUT (M10) Brass/Nickel Plated
|
12 |
|
| 38 |
90196 |
O-RING (.921 x .139) Top Cover
|
1 |
superseded
|
| 39 |
880041A1 |
COVER ASSEMBLY Top Of Jet Drive Housing
|
1 |
|
| 4 |
76868 |
SEAL Oil
|
2 |
superseded
|
| 40 |
20826 |
O-RING (2.230 x .139) Top Cover
|
1 |
|
| 41 |
883051 |
GASKET Engine Adaptor
|
1 |
|
| 42 |
884845 |
STUD (M10 x 63)
|
12 |
disc.
|
| 43 |
70146 |
CONNECTOR Barbed (.250-18)
|
1 |
|
| 5 |
63742T |
BEARING Ball
|
1 |
|
| 6 |
55626 |
RING Snap
|
1 |
|
| 7 |
79953Q2 |
SCREW KIT (.375-16 x .250) Drain
|
2 |
superseded
|
| 8 |
191832 |
WASHER Sealing
|
2 |
superseded
|
| 9 |
859452 |
GASKET Drive Housing To Top Cover
|
1 |
|
