| # | Part Number | Description | Qty | Status |
|---|
| 1 |
85606065 |
TUBING (38.00 Inches Bulk) Cut 11.500 Inches
|
2 |
superseded
|
| 10 |
856156A2 |
SWITCH ASSEMBLY Low Oil
|
1 |
superseded
|
| 11 |
814449A3 |
CAP ASSEMBLY
|
1 |
|
| 12 |
42999 |
GASKET
|
1 |
superseded
|
| 13 |
81893435 |
SCREW (M8 x 35)
|
3 |
|
| 14 |
4002318 |
WASHER 8.90 x 24.0x 2.4 PL SS
|
3 |
|
| 15 |
855362 |
GROMMET
|
3 |
superseded
|
| 16 |
855364 |
BUSHING
|
3 |
|
| 17 |
816311T |
TIE STRAP (8.00 Inches)
|
3 |
|
| 18 |
85583466 |
HOSE (40.00 Inches Bulk) Cut As Required
|
1 |
superseded
|
| 19 |
859230 |
RETAINER Hose Support
|
2 |
superseded
|
| 2 |
85606065 |
TUBING (38.00 Inches Bulk) Cut 5.00 Inches
|
1 |
superseded
|
| 20 |
858870 |
CHECK VALVE
|
6 |
|
| 21 |
85606065 |
TUBING (38.00 Inches Bulk) Cut 19.500 Inches
|
1 |
superseded
|
| 22 |
56762 |
TIE STRAP (4.00 Inches)
|
6 |
|
| 23 |
85606065 |
TUBING (38.00 Inches Bulk) Cut 11.500 Inches
|
1 |
superseded
|
| 24 |
85606065 |
TUBING (38.00 Inches Bulk) Cut 6.00 Inches
|
1 |
superseded
|
| 25 |
56762 |
TIE STRAP (4.00 Inches)
|
13 |
|
| 26 |
85606065 |
TUBING (38.00 Inches Bulk) Cut 4.00 Inches
|
1 |
superseded
|
| 27 |
85606065 |
TUBING (38.00 Inches Bulk) Cut 15.500 Inches
|
1 |
superseded
|
| 28 |
85606065 |
TUBING (38.00 Inches Bulk) Cut 20.500 Inches
|
1 |
superseded
|
| 29 |
82381455 |
TUBING (25.00 Inches Bulk) Cut 22.00 Inches
|
1 |
|
| 3 |
18206 |
FILTER Inline Fuel
|
2 |
superseded
|
| 30 |
816311T |
TIE STRAP (8.00 Inches)
|
3 |
|
| 31 |
830756109 |
HOSE (57.00 Inches Bulk) Cut 7.00 Inches
|
1 |
superseded
|
| 32 |
424254 |
FITTING
|
1 |
superseded
|
| 33 |
875283 |
HOSE (2.00 Inches)
|
1 |
|
| 34 |
69355 |
TIE STRAP (5.50 Inches)
|
1 |
superseded
|
| 35 |
875284 |
FILTER In Line
|
1 |
superseded
|
| 36 |
NSS |
NOT SOLD SEPARATE Plug
|
1 |
|
| 4 |
85606065 |
TUBING (38.00 Inches Bulk) Cut 9.00 Inches
|
1 |
superseded
|
| 5 |
8245021 |
CONNECTOR
|
1 |
|
| 6 |
830889A4 |
TANK ASSEMBLY Oil
|
1 |
superseded
|
| 7 |
NSS |
NOT SOLD SEPARATE Info Decal - Overflow If Cap Is Loose
|
1 |
|
| 7 |
881865 |
DECAL Caution-Start in Gear
|
1 |
|
| 8 |
58376 |
SCREW (.164-18 x .375)
|
1 |
|
| 9 |
72761 |
WASHER (.203 x .562 x .060) Stainless Steel
|
1 |
|
