| # | Part Number | Description | Qty | Status |
|---|
| - |
889437A2 |
POWERHEAD ASSEMBLY
|
1 |
disc.
|
| 1 |
883078A4 |
INJECTOR KIT Air
|
6 |
superseded
|
| 10 |
883542 |
VALVE ASSEMBLY (.375 Inch Diameter) Fuel
|
1 |
superseded
|
| 11 |
804840 |
O-RING KIT
|
1 |
|
| 12 |
804526 |
SCREW PACKAGE (M5 x 16) (2 Per)
|
4 |
|
| 13 |
804535 |
COVER Pressure Tracker
|
1 |
superseded
|
| 14 |
804534 |
SPRING
|
1 |
|
| 15 |
804536 |
O-RING
|
1 |
|
| 16 |
804533 |
DIAPHRAGM ASSEMBLY
|
1 |
|
| 17 |
291112 |
FITTING Straight
|
1 |
|
| 18 |
804832 |
CLAMP
|
2 |
|
| 19 |
880816 |
CLAMP
|
1 |
superseded
|
| 2 |
804875 |
SEAL KIT Air Injectors
|
6 |
|
| 20 |
804837 |
VALVE ASSEMBLY (.5 Inch Diameter) Air
|
1 |
disc.
|
| 21 |
804831 |
CLAMP
|
4 |
superseded
|
| 22 |
804530 |
O-RING KIT Contains 6 pcs
|
1 |
|
| 23 |
804529 |
O-RING KIT Contains 6 pcs
|
1 |
|
| 24 |
804835 |
PLUG Air
|
1 |
|
| 25 |
996642 |
FITTING Elbow 90 Degree (.125-27 x .250) Nylon
|
1 |
|
| 26 |
804528 |
INJECTOR Fuel
|
6 |
superseded
|
| 27 |
804532 |
O-RING KIT (16 Per Kit)
|
1 |
|
| 28 |
804829 |
HOSE ASSEMBLY Air Balance - Rail To Rail
|
1 |
disc.
|
| 29 |
889429 |
HOSE ASSEMBLY Fuel Balance - Rail To Rail
|
1 |
disc.
|
| 3 |
828694A1 |
WASHER ASSEMBLY Cupped
|
6 |
|
| 30 |
889428 |
HOSE ASSEMBLY Fuel Supply - To Vapor Separator Upper
|
1 |
|
| 31 |
889427 |
HOSE ASSEMBLY Air By Pass - To Adaptor Plate Elbow
|
1 |
|
| 32 |
889426 |
HOSE ASSEMBLY Fuel By Pass - To Vapor Separator Lower
|
1 |
disc.
|
| 33 |
880141 |
CLAMP (18.3)
|
2 |
|
| 34 |
858778 |
STUD (M10 x 91)
|
4 |
superseded
|
| 35 |
826292 |
NUT (M10) Brass/Nickel Plated
|
4 |
|
| 36 |
858939 |
SCREW (M5 x 35)
|
1 |
disc.
|
| 37 |
8583253 |
CLAMP Hose Support
|
1 |
disc.
|
| 38 |
859376 |
CLIP Conduit Support
|
4 |
|
| 39 |
815504104 |
CLAMP Worm Gear
|
1 |
|
| 4 |
895747T01 |
FUEL RAIL ASSEMBLY Port And Starboard
|
1 |
superseded
|
| 5 |
804836 |
FITTING
|
1 |
|
| 6 |
804532 |
O-RING KIT (16 Per Kit)
|
1 |
|
| 7 |
804830 |
CLAMP
|
4 |
|
| 8 |
804525 |
SCREW PACKAGE (M5 x 8) (2 Per)
|
15 |
superseded
|
| 9 |
805515 |
CAP Shrader Valve - Brass
|
2 |
disc.
|
