| # | Part Number | Description | Qty | Status |
|---|
| 1 |
8583541 |
LINK Throttle
|
1 |
|
| 10 |
8252682 |
LEVER Throttle Control
|
1 |
superseded
|
| 11 |
35459 |
WASHER
|
1 |
|
| 12 |
401386 |
NUT (M6) Stainless Steel
|
1 |
|
| 13 |
8240102 |
BRACKET Anchor
|
1 |
superseded
|
| 14 |
42975 |
DRIVE SCREW Special
|
2 |
|
| 15 |
824016 |
LATCH Control Cable
|
1 |
|
| 16 |
824015 |
CUP Barrel Retainer
|
2 |
|
| 17 |
859172 |
CLAMP
|
1 |
|
| 18 |
29245 |
WASHER (.281 x .500 x .060) Stainless Steel
|
1 |
superseded
|
| 19 |
82155025 |
SCREW (M8 x 25 MM) Stainless Steel
|
2 |
|
| 2 |
932481 |
BUSHING Swivel
|
1 |
superseded
|
| 20 |
932481 |
BUSHING Swivel
|
1 |
superseded
|
| 21 |
858353T5 |
CAM ASSEMBLY
|
1 |
|
| 22 |
8235694 |
BALL Threaded
|
1 |
|
| 23 |
883948 |
BUSHING
|
1 |
superseded
|
| 24 |
40011155 |
SCREW (M8 x 55) Stainless Steel
|
1 |
|
| 3 |
81893435 |
SCREW (M8 x 35)
|
1 |
|
| 4 |
36042 |
WASHER
|
1 |
|
| 5 |
400212 |
NUT (M6) Stainless Steel
|
2 |
|
| 6 |
40124 |
SCREW (M6 x 55)
|
2 |
|
| 7 |
42942 |
CAP
|
2 |
|
| 8 |
821113 |
BUSHING
|
1 |
|
| 9 |
42927 |
INSERT
|
1 |
|
