| # | Part Number | Description | Qty | Status |
|---|
| 1 |
878082T06 |
HARNESS ASSEMBLY Engine
|
1 |
|
| 10 |
816311T |
TIE STRAP (8.00 Inches)
|
AR |
|
| 11 |
858366T2 |
PLATE Relay/Solenoid Mount
|
1 |
|
| 12 |
82130012 |
SCREW (M6 x 12)
|
3 |
|
| 13 |
858755 |
CLIP (1.00)
|
1 |
|
| 14 |
817109A2 |
SOLENOID ASSEMBLY (#10-32 / .3125-18 Terminals)
|
1 |
|
| 15 |
822179 |
GROMMET
|
2 |
|
| 16 |
818968 |
BUSHING
|
2 |
superseded
|
| 17 |
828991 |
CLIP
|
1 |
superseded
|
| 18 |
82129114 |
SCREW (M6 x 14) Ground Screws
|
2 |
|
| 19 |
882751A1 |
RELAY ASSEMBLY
|
1 |
superseded
|
| 2 |
83296920 |
FUSE Mini - Yellow - 20 Ampere
|
4 |
superseded
|
| 2 |
83296915 |
FUSE Mini - Blue - 15 Ampere
|
1 |
superseded
|
| 20 |
828102 |
BRACKET
|
1 |
superseded
|
| 21 |
818968 |
BUSHING
|
1 |
superseded
|
| 22 |
818967 |
GROMMET
|
1 |
|
| 23 |
NSS |
NOT SOLD SEPARATE Relay Decal
|
1 |
|
| 24 |
82129125 |
SCREW (M6 x 25 MM)
|
3 |
|
| 25 |
88807A16 |
CABLE ASSEMBLY (4.00 Inches) Black
|
1 |
|
| 26 |
45076 |
NUT (#10-32) Brass
|
2 |
|
| 27 |
813938 |
CAP NUT (#10-32)
|
1 |
|
| 28 |
878231A6 |
HARNESS ASSEMBLY Fuse - 100 Ampere (34.00 Inches)
|
1 |
|
| 29 |
882829A1 |
CABLE ASSEMBLY Starter
|
1 |
|
| 3 |
858754 |
COVER Fuse
|
1 |
|
| 30 |
53166 |
LOCKWASHER (.312)
|
2 |
|
| 31 |
68292 |
NUT (.312-18)
|
2 |
superseded
|
| 32 |
830233 |
BOOT Insulator - Red
|
1 |
|
| 33 |
29245 |
WASHER (.281 x .500 x .060) Stainless Steel
|
1 |
superseded
|
| 34 |
8500673 |
BOOT Insulator - Yellow
|
1 |
|
| 35 |
856954 |
BUSHING
|
3 |
|
| 36 |
834985 |
GROMMET
|
3 |
superseded
|
| 37 |
85961043 |
PCM Propulsion Control Module [0E407100] THRU [0E414099]
|
1 |
superseded
|
| 37 |
85961004S |
PCM Propulsion Control Module [0E414100] THRU [0E418195]
|
1 |
superseded
|
| 37 |
85961008S |
PCM Propulsion Control Module [0E418196] THRU [0E419435]
|
1 |
superseded
|
| 37 |
88555717T |
PCM Propulsion Control Module [0E419436] THRU [0E434192]
|
1 |
superseded
|
| 37 |
89790638T |
PCM Propulsion Control Module [0E434193] & Up
|
1 |
|
| 38 |
65567 |
WASHER (.265 x .750 x .048) Stainless Steel
|
3 |
|
| 39 |
82130025 |
SCREW (M6 x 25)
|
3 |
|
| 4 |
828547353 |
CONDUIT (.350 Inside Diameter x 3.00 Feet Bulk) Cut As Required
|
AR |
|
| 4 |
828547T1 |
CONDUIT (.500 Inside Diameter x 3.00 Feet Bulk) Cut As Required
|
AR |
|
| 4 |
828547633 |
CONDUIT (.620 Inside Diameter x 3.00 Feet Bulk) Cut As Required
|
AR |
|
| 4 |
828547T |
CONDUIT (1.00 Inside Diameter x 3.00 Feet Bulk) Cut As Required
|
AR |
|
| 40 |
858953 |
BRACKET
|
1 |
|
| 41 |
8590881 |
CLIP
|
1 |
|
| 42 |
82129114 |
SCREW (M6 x 14)
|
2 |
|
| 43 |
859376 |
CLIP Conduit Support
|
1 |
|
| 44 |
889570A02 |
WIRE ASSEMBLY Oil Light Driver - NOTE: 250 DFI M2 Models Only
|
1 |
disc.
|
| 5 |
828054 |
COVER Fuse
|
1 |
|
| 6 |
862646 |
FUSE Tan - 5 Ampere
|
1 |
|
| 7 |
13541 |
PLUG Male
|
2 |
|
| 8 |
13540 |
CAP Female
|
1 |
|
| 9 |
832948A1 |
CONNECTOR ASSEMBLY 2 POS Male
|
1 |
|
