| # | Part Number | Description | Qty | Status |
|---|
| - |
MXC30047T |
FOOT PEDAL ASSEMBLY Complete Marked MXC300472
|
1 |
disc.
|
| 1 |
MAP32747T |
CABLE ASSEMBLY Control (69.00 Inches) Marked MAP327472
|
1 |
disc.
|
| 10 |
MPM15303 |
SWITCH ASSEMBLY Toggle - Design I - With Soldered Wires
|
1 |
superseded
|
| 10 |
879330T33 |
SWITCH ASSEMBLY Toggle - Design II - Used With Terminals MBR16103
|
1 |
|
| 11 |
MFM13303 |
SCREW (#10-32 x .375)
|
2 |
superseded
|
| 12 |
MPM01901 |
GROMMET
|
1 |
disc.
|
| 13 |
MFM00601 |
COLLAR Retainer
|
1 |
superseded
|
| 14 |
MPM00304T |
BASE Foot Pedal Bottom
|
1 |
disc.
|
| 15 |
896785 |
SWITCH ASSEMBLY Toggle
|
1 |
superseded
|
| 16 |
MFP17701 |
BOOT Toggle Switch
|
2 |
superseded
|
| 17 |
MAT05714 |
DECAL Toggle Switch
|
1 |
superseded
|
| 18 |
MFM13305 |
SHOULDER BOLT (#10-32 x .640)
|
2 |
superseded
|
| 19 |
MPM12104 |
PULLEY Foot Pedal Cable - Plastic - Design I - Replace Both Pulleys At Same Time - Do Not Intermix
|
2 |
superseded
|
| 19 |
M879321T |
PULLEY Foot Pedal Cable - Stainless Steel - Design II - Replace Both Pulleys At Same Time - Do Not Intermix
|
2 |
|
| 2 |
MPP327022 |
CABLE ASSEMBLY Transducer
|
1 |
superseded
|
| 20 |
MAP03601 |
CLAMP Cable
|
1 |
superseded
|
| 21 |
MBK04601 |
E RING
|
1 |
superseded
|
| 22 |
MPM10201 |
PIN Foot Pedal
|
1 |
superseded
|
| 23 |
26954 |
BUSHING
|
2 |
|
| 24 |
MAP15103S |
SWITCH KIT Micro
|
1 |
disc.
|
| 25 |
MPM02602 |
COVER Switch
|
1 |
superseded
|
| 26 |
MPM13501 |
SCREW (#6-32 x 1.12)
|
2 |
superseded
|
| 27 |
MSP09802 |
NUT (#6-32)
|
2 |
superseded
|
| 28 |
818853 |
RING Retaining
|
1 |
|
| 29 |
MPM08201 |
KNOB ASSEMBLY Variable Speed
|
1 |
superseded
|
| 3 |
MPM02703 |
CABLE ASSEMBLY Steering - Short
|
1 |
superseded
|
| 30 |
56762 |
TIE STRAP (4.00 Inches)
|
1 |
|
| 31 |
MPM10104T |
BASE Foot Pedal Top
|
1 |
disc.
|
| 32 |
MPM05703 |
DECAL
|
1 |
superseded
|
| 33 |
MPM05401 |
PAD Foot Plate
|
1 |
superseded
|
| 34 |
MPM02301 |
BUMPER (#8-32) Rubber
|
4 |
superseded
|
| 4 |
MPM02704 |
CABLE ASSEMBLY Steering - Long
|
1 |
superseded
|
| 5 |
MPM01401 |
SPRING
|
2 |
superseded
|
| 6 |
MPM09802 |
NUT (.312-24)
|
2 |
superseded
|
| 7 |
MM900625 |
TUBING (25.00 Feet Bulk) Cut As Required
|
1 |
disc.
|
| 8 |
816311T |
TIE STRAP (8.00 Inches)
|
2 |
|
| 9 |
MAP16803 |
POTENTIOMETER ASSEMBLY
|
1 |
superseded
|
