| # | Part Number | Description | Qty | Status |
|---|
| - |
879317T89 |
FOOT PEDAL ASSEMBLY Complete Marked 8M4001826
|
1 |
disc.
|
| 1 |
879364T01 |
CABLE ASSEMBLY Control (63.00 Inches) Marked 8M4001818
|
1 |
disc.
|
| 10 |
879330T33 |
SWITCH ASSEMBLY Toggle Used With Terminals MBR16103T
|
1 |
|
| 11 |
MFM13303T |
SCREW (#10-32 x .375)
|
2 |
disc.
|
| 12 |
MFM00601T |
COLLAR Retainer
|
1 |
|
| 13 |
MPM00304T |
BASE Foot Pedal Bottom
|
1 |
disc.
|
| 14 |
896785T |
SWITCH ASSEMBLY Toggle
|
1 |
|
| 15 |
MFP17701T |
BOOT Toggle Switch
|
2 |
disc.
|
| 16 |
MAT05714T |
DECAL Toggle Switch
|
1 |
disc.
|
| 17 |
MFM13305T |
SHOULDER BOLT (#10-32 x .640)
|
2 |
disc.
|
| 18 |
M879321T |
PULLEY Foot Pedal Cable - Stainless Steel
|
2 |
|
| 19 |
MAP03601T |
CLAMP Cable
|
1 |
disc.
|
| 2 |
879364T03 |
CABLE ASSEMBLY Transducer Marked 8M4001817
|
1 |
|
| 20 |
MBK04601T |
E RING
|
1 |
|
| 21 |
MPM10201T |
PIN Foot Pedal
|
1 |
disc.
|
| 22 |
26954 |
BUSHING
|
2 |
|
| 23 |
MAP15103S |
SWITCH KIT Micro
|
1 |
disc.
|
| 24 |
MPM02602T |
COVER Switch
|
1 |
|
| 25 |
MPM13501T |
SCREW (#6-32 x 1.12)
|
2 |
disc.
|
| 26 |
MSP09802T |
NUT (#6-32)
|
2 |
disc.
|
| 27 |
818853 |
RING Retaining
|
1 |
|
| 28 |
MPM08201T |
KNOB ASSEMBLY Variable Speed
|
1 |
superseded
|
| 29 |
56762 |
TIE STRAP (4.00 Inches)
|
1 |
|
| 3 |
MPM02753T |
CABLE ASSEMBLY Steering - Short
|
1 |
superseded
|
| 30 |
MPM10104T |
BASE Foot Pedal Top
|
1 |
disc.
|
| 31 |
MPM05703T |
DECAL
|
1 |
disc.
|
| 32 |
MPM05401T |
PAD Foot Plate
|
1 |
|
| 33 |
MPM02301T |
BUMPER (#8-32)
|
4 |
disc.
|
| 4 |
MPM02754T |
CABLE ASSEMBLY Steering - Long
|
1 |
superseded
|
| 5 |
MPM01401T |
SPRING
|
2 |
disc.
|
| 6 |
MPM09802T |
NUT (.312-24)
|
2 |
disc.
|
| 7 |
MM900625 |
TUBING (25.00 Feet Bulk)
|
1 |
disc.
|
| 8 |
816311T |
TIE STRAP (8.00 Inches)
|
2 |
|
| 9 |
MAP16803T |
POTENTIOMETER ASSEMBLY
|
1 |
|
