| # | Part Number | Description | Qty | Status |
|---|
| - |
MST9205BF |
MOUNT ASSEMBLY Complete Model 20.5 - NOTE: See Mount Assembly Section For Service Parts Breakdown
|
1 |
superseded
|
| 1 |
MET05317J |
COVER Top
|
1 |
superseded
|
| 10 |
MAT16504 |
TUBE Outer Handle
|
1 |
superseded
|
| 11 |
MBT02201 |
BUSHING Inner Handle
|
1 |
superseded
|
| 12 |
MAT11001 |
PIN Roll
|
1 |
superseded
|
| 13 |
MAF14301 |
SET SCREW (#10)
|
1 |
superseded
|
| 14 |
MAT316832 |
POTENTIOMETER ASSEMBLY
|
1 |
superseded
|
| 15 |
MAT15505 |
BRACKET
|
1 |
superseded
|
| 16 |
MAR03602 |
CLAMP Handle Retainer
|
1 |
superseded
|
| 17 |
MBF02901 |
CONNECTOR Pigtail (#18-8)
|
3 |
superseded
|
| 17 |
MBF02902 |
CONNECTOR Pigtail (#22-14)
|
3 |
superseded
|
| 18 |
MAF03001 |
TIE STRAP (.16 x 7/8.00 Inches)
|
1 |
superseded
|
| 19 |
MAT15506 |
PLATE Cable - Design I - NOTE: Replaced With MAT15504
|
1 |
superseded
|
| 2 |
MFT19022 |
DECAL Top Cover Bassmaster Digital 70 Lbs Thrust 24 Volt
|
1 |
superseded
|
| 20 |
MFP15307 |
SWITCH ASSEMBLY Toggle
|
1 |
superseded
|
| 21 |
MAT05714 |
DECAL Toggle Switch
|
1 |
superseded
|
| 22 |
MFP17701 |
BOOT Toggle Switch
|
1 |
superseded
|
| 23 |
MAT15504 |
BRACKET - Design II - NOTE: Replaces MAT15506 Cable Plate
|
1 |
superseded
|
| 24 |
MKP03604 |
P CLAMP (#10 x .375) - Design II - NOTE: Used With MAT15504
|
1 |
superseded
|
| 25 |
MTT13402 |
BOLT (.250-20 x 1.75)
|
1 |
superseded
|
| 26 |
MTT17108 |
WASHER Curved
|
2 |
superseded
|
| 27 |
MXT09802 |
LOCKNUT (.250-20) Stainless Steel
|
1 |
superseded
|
| 28 |
MET004167 |
COVER Bottom
|
1 |
superseded
|
| 29 |
MAT07901 |
SEAL Column
|
1 |
superseded
|
| 3 |
MAT14101 |
SCREW (#8 x .625) Stainless Steel
|
9 |
superseded
|
| 30 |
MTM15804 |
COLLAR ASSEMBLY Depth Adjust - Black - 5 Lobe Style
|
1 |
superseded
|
| 31 |
MFR04913 |
COLUMN (50.00 Inches) Stainless Steel
|
1 |
superseded
|
| 32 |
MKM08205 |
KNOB Friction
|
1 |
superseded
|
| 33 |
MRK02102 |
TUBE Friction
|
1 |
superseded
|
| 34 |
MGR01901 |
BUSHING Battery Cable
|
1 |
superseded
|
| 35 |
MXT328062 |
CABLE ASSEMBLY Battery
|
1 |
superseded
|
| 36 |
MUC397012 |
LOWER UNIT ASSEMBLY Complete (71# - Variable) - NOTE: See Lower Unit Assembly Section For Service Parts Breakdown
|
1 |
superseded
|
| 37 |
MAR17501 |
WASHER (.385 x .885 x .095) Nylon
|
1 |
superseded
|
| 38 |
MAF174555 |
PROP KIT 3 Blade Nylon - 3.5 Inch - Machete - Taper Hub - Design I - With Nylon Prop Nut
|
1 |
superseded
|
| 38 |
MAF174755 |
PROP KIT 3 Blade Nylon - 3.5 Inch - Machete - Taper Hub - Design II - With Brass Insert Prop Nut
|
1 |
superseded
|
| 39 |
MAF12415 |
PROPELLER 3 Blade Nylon - 3.5 Inch - Machete - Taper Hub
|
1 |
superseded
|
| 4 |
MAR03604 |
RETAINER Handle Without Stop
|
1 |
superseded
|
| 40 |
MBR10202 |
PIN Prop Drive (.156 x 1.00)
|
1 |
superseded
|
| 41 |
MAR09901 |
PROP NUT - Design I - All Nylon
|
1 |
superseded
|
| 41 |
MAR09902 |
PROP NUT - Design II - Nylon With Brass Insert
|
1 |
superseded
|
| 42 |
MDK13301 |
SCREW (.250-20 x .750)
|
1 |
superseded
|
| 43 |
MAR00202 |
ANODE Zinc - Design I
|
1 |
superseded
|
| 43 |
M879341T |
ANODE Aluminum - Design II
|
1 |
disc.
|
| 5 |
MET372072 |
HANDLE ASSEMBLY
|
1 |
superseded
|
| 6 |
MBT07002 |
GRIP Handle
|
1 |
superseded
|
| 7 |
MAT05903 |
DECAL Speed Indicator - Design I - Turtles - Arrows - Rabbits
|
1 |
superseded
|
| 7 |
MAT05905 |
DECAL Speed Indicator - Design II - Indicator Markers - Rabbits
|
1 |
superseded
|
| 8 |
MBT07901 |
SEAL Felt
|
1 |
superseded
|
| 9 |
MBT02202 |
BUSHING Handle Guide
|
1 |
superseded
|
