| # | Part Number | Description | Qty | Status |
|---|
| 1 |
MET05317H |
COVER Top
|
1 |
superseded
|
| 10 |
MAT07901 |
SEAL Column
|
1 |
superseded
|
| 11 |
MAR15801 |
COLLAR ASSEMBLY Depth Adjust
|
1 |
superseded
|
| 12 |
MFR04914 |
COLUMN (36.00 Inches) Stainless Steel
|
1 |
superseded
|
| 12 |
MFR04912 |
COLUMN (42.00 Inches) Stainless Steel
|
1 |
superseded
|
| 12 |
MFR04913 |
COLUMN (50.00 Inches) Stainless Steel
|
1 |
superseded
|
| 13 |
MAR17501 |
WASHER (.385 x .885 x .095) Nylon
|
1 |
superseded
|
| 14 |
MBR10201 |
PIN Prop Drive (.125 x 1.00)
|
1 |
superseded
|
| 15 |
MAF12407 |
PROPELLER 2 Blade Nylon - 3.5 Inch
|
1 |
superseded
|
| 15 |
MAF12412 |
PROPELLER 3 Blade Nylon - 3.5 Inch - Machete II
|
1 |
superseded
|
| 16 |
MAR09901 |
PROP NUT
|
1 |
superseded
|
| 17 |
MDK13301 |
SCREW (.250-20 x .750) - Saltwater Models Only
|
1 |
superseded
|
| 18 |
MAR00202 |
ANODE Zinc - Saltwater Models Only
|
1 |
superseded
|
| 19 |
MCM397042 |
LOWER UNIT ASSEMBLY Complete (45# - Variable) - NOTE: See Lower Unit Assembly Section For Service Parts Breakdown
|
1 |
disc.
|
| 2 |
MET372062 |
HANDLE ASSEMBLY
|
1 |
superseded
|
| 20 |
MET06008 |
DECAL MotorGuide Hyper Drive
|
1 |
superseded
|
| 21 |
MFP17701 |
BOOT Toggle Switch
|
1 |
superseded
|
| 22 |
MFP15307 |
SWITCH ASSEMBLY Toggle
|
1 |
superseded
|
| 23 |
MAT15506 |
PLATE Cable
|
1 |
superseded
|
| 24 |
MAR03602 |
CLAMP Handle Retainer
|
1 |
superseded
|
| 25 |
MAR03604 |
RETAINER Handle
|
1 |
superseded
|
| 26 |
MTT05612 |
DECAL Top Cover
|
1 |
disc.
|
| 27 |
MXT328062 |
CABLE ASSEMBLY Battery
|
1 |
superseded
|
| 28 |
MGR01901 |
BUSHING Battery Cable
|
1 |
superseded
|
| 3 |
MAT14101 |
SCREW (#8 x .625) Stainless Steel
|
9 |
superseded
|
| 4 |
MXT14101 |
SCREW (#4 x .312)
|
2 |
disc.
|
| 5 |
MAT15701C |
BOARD ASSEMBLY (12V) - NOTE: Part No Longer Available - Reference Service Bulletin 2004-02
|
1 |
superseded
|
| 6 |
MTT13402 |
BOLT (.250-20 x 1.75)
|
1 |
superseded
|
| 7 |
MTT17108 |
WASHER Curved
|
2 |
superseded
|
| 8 |
MXT09802 |
LOCKNUT (.250-20) Stainless Steel
|
1 |
superseded
|
| 9 |
MAT004118 |
COVER Bottom
|
1 |
superseded
|
