| # | Part Number | Description | Qty | Status |
|---|
| - |
883298A1 |
GASKET/SEAL SET Powerhead - NOTE: See Gasket/Seal Set - Powerhead Section For Parts Breakdown
|
1 |
|
| - |
858961A19 |
POWERHEAD ASSEMBLY
|
1 |
superseded
|
| 1 |
996642 |
FITTING Elbow 90 Degree (.125-27 x .250) Nylon
|
1 |
|
| 10 |
61001 |
J CLIP
|
1 |
|
| 11 |
859432 |
FITTING
|
1 |
superseded
|
| 12 |
85978568 |
TUBING (44.00 Inches Bulk) Cut 26.00 Inches
|
1 |
superseded
|
| 13 |
859431 |
FITTING
|
1 |
superseded
|
| 14 |
859596 |
SENSOR (0-50 PSI) Water Pressure
|
1 |
superseded
|
| 15 |
858954 |
CLIP (.625)
|
1 |
|
| 16 |
F698772 |
CLAMP Worm Gear
|
2 |
|
| 17 |
687271 |
FITTING (.250-18) 90 Degree - Brass
|
1 |
|
| 18 |
68728 |
FITTING
|
1 |
disc.
|
| 19 |
77653101 |
HOSE (48.00 Inches Bulk) Cut 21.00 Inches
|
1 |
|
| 2 |
815504206 |
CLAMP Worm Gear
|
2 |
|
| 20 |
42683 |
CONNECTOR (.750-14)
|
1 |
|
| 21 |
815504310 |
CLAMP Worm Gear
|
2 |
|
| 22 |
4285069 |
HOSE (44.00 Inches Bulk) Cut As Required
|
1 |
superseded
|
| 23 |
815504104 |
CLAMP Worm Gear
|
3 |
|
| 24 |
858459 |
FITTING
|
1 |
|
| 25 |
83075821 |
TUBING (6.00 Inches Bulk) Cut 5.250 Inches - Design I
|
3 |
|
| 26 |
816311T |
TIE STRAP (8.00 Inches) - Design I
|
3 |
|
| 27 |
16604 |
FITTING Straight (.125-27) - Design I
|
2 |
|
| 27 |
884591 |
FITTING 45 Degree (1.25-27) - Design II
|
2 |
|
| 28 |
BOATPART |
SEE BOAT MANUFACTURER Hose - To Thru Hull Fitting
|
1 |
|
| 29 |
856981 |
NUT (.562-18)
|
1 |
|
| 3 |
881215A1 |
HOSE ASSEMBLY (32.00 Inches)
|
1 |
superseded
|
| 30 |
856867 |
FITTING Cool Water Vent
|
1 |
|
| 31 |
83075821 |
TUBING (6.00 Inches Bulk) Cut 5.250 Inches - Design II
|
2 |
|
| 32 |
816311T |
TIE STRAP (8.00 Inches) - Design II
|
5 |
|
| 33 |
83075821 |
TUBING (6.00 Inches Bulk) Cut 2.00 Inches - Design II
|
1 |
|
| 34 |
83075821 |
TUBING (6.00 Inches Bulk) Cut 3.00 Inches - Design II
|
1 |
|
| 35 |
883619 |
CONNECTOR Elbow - Design II
|
1 |
|
| 4 |
877311 |
FITTING With Strainer
|
1 |
|
| 5 |
45711 |
O-RING (.612 x .103)
|
1 |
|
| 6 |
816311T |
TIE STRAP (8.00 Inches)
|
2 |
|
| 7 |
85833935 |
TUBING (15.00 Inches Bulk) Cut 4.500 Inches - Air Bypass
|
1 |
superseded
|
| 8 |
291112 |
FITTING Straight
|
1 |
|
| 9 |
98257 |
SCREW (.312-18 x .500)
|
1 |
|
