| # | Part Number | Description | Qty | Status |
|---|
| - |
858961A19 |
POWERHEAD ASSEMBLY
|
1 |
superseded
|
| 1 |
8742A20 |
TANK ASSEMBLY Remote Oil Complete - Design I - With 12335A1 Hold Down Bracket
|
1 |
superseded
|
| 1 |
8742A22 |
TANK ASSEMBLY Remote Oil Complete - Design II - With 884481A1 Hold Down Bracket
|
1 |
|
| 1 |
87421 |
TANK Oil
|
1 |
|
| 10 |
11332 |
O-RING (2.225 x .210)
|
1 |
|
| 11 |
99802 |
TUBE Oil Pick Up
|
1 |
|
| 12 |
99439 |
HOSE (114.00 Inches) Oil Line
|
1 |
|
| 13 |
816311T |
TIE STRAP (8.00 Inches)
|
5 |
|
| 14 |
878105 |
CHECK VALVE Crankcase
|
1 |
superseded
|
| 15 |
NSS |
NOT SOLD SEPARATE Yellow Plug
|
2 |
|
| 16 |
833069T9 |
RESERVOIR ASSEMBLY Oil
|
1 |
superseded
|
| 17 |
855364 |
BUSHING
|
3 |
|
| 18 |
855362 |
GROMMET
|
3 |
superseded
|
| 19 |
856156A2 |
SWITCH ASSEMBLY Low Oil
|
1 |
superseded
|
| 2 |
12335A1 |
BRACKET KIT Oil Tank Hold Down - Design I
|
1 |
|
| 2 |
884481A1 |
BRACKET KIT Oil Tank Hold Down - Design II
|
1 |
|
| 20 |
58376 |
SCREW (.164-18 x .375)
|
1 |
|
| 21 |
72761 |
WASHER (.203 x .562 x .060) Stainless Steel
|
1 |
|
| 22 |
49436 |
WASHER
|
3 |
|
| 23 |
60411 |
SCREW (.312-18 x 1.250)
|
3 |
|
| 24 |
NSS |
NOT SOLD SEPARATE Reservoir Info Decal
|
1 |
|
| 25 |
814634 |
CLAMP
|
1 |
|
| 26 |
875284 |
FILTER In Line Oil
|
1 |
superseded
|
| 27 |
69355 |
TIE STRAP (5.50 Inches)
|
4 |
superseded
|
| 28 |
875283 |
HOSE (2.00 Inches)
|
1 |
|
| 29 |
858955 |
CONNECTOR
|
1 |
|
| 3 |
12323A1 |
CORD/HOOK KIT
|
1 |
|
| 30 |
816311T |
TIE STRAP (8.00 Inches)
|
4 |
|
| 31 |
830756109 |
HOSE (57.00 Inches Bulk) Cut 4.750 Inches
|
1 |
superseded
|
| 32 |
424254 |
FITTING Check
|
1 |
superseded
|
| 33 |
830756109 |
HOSE (57.00 Inches Bulk) Cut 6.00 Inches
|
1 |
superseded
|
| 34 |
15969A3 |
DECK FILL KIT Oil
|
OPT |
|
| 35 |
15969A5 |
DECK FILL KIT Oil
|
1 |
superseded
|
| 36 |
15966 |
PLATE
|
1 |
|
| 37 |
815504228 |
CLAMP Worm Gear
|
2 |
|
| 38 |
15967 |
ADAPTER Oil Filler
|
1 |
|
| 39 |
11332 |
O-RING (2.225 x .210)
|
1 |
|
| 4 |
12320 |
BRACKET Hold Down
|
2 |
|
| 40 |
850719 |
HOSE (100.00 Feet Bulk) Cut As Required - Oil Filler
|
AR |
|
| 5 |
79968 |
SCREW (#12-11 x .750)
|
4 |
|
| 6 |
43298A2 |
CAP ASSEMBLY Oil Tank
|
1 |
|
| 7 |
11332 |
O-RING (2.225 x .210)
|
1 |
|
| 8 |
816190A4 |
OIL PICK UP ASSEMBLY Without Sender
|
1 |
|
| 9 |
43298A2 |
CAP ASSEMBLY Housing Adaptor
|
1 |
|
