| # | Part Number | Description | Qty | Status |
|---|
| 1 |
859734T1 |
FLYWHEEL
|
1 |
|
| 10 |
4002320 |
WASHER
|
2 |
|
| 11 |
856894 |
BUSHING
|
1 |
superseded
|
| 12 |
856815T2 |
ARM TENSIONER ASSEMBLY
|
1 |
|
| 13 |
855798001 |
SPRING
|
1 |
|
| 14 |
40108100 |
SCREW (M10 x 100) Hex Flange - Stainless Steel
|
1 |
superseded
|
| 15 |
40108120 |
SCREW (M10 x 120) Hex Flange - Stainless Steel
|
1 |
|
| 16 |
845998 |
WASHER (.406 x 1.250 x .089)
|
3 |
|
| 17 |
858391T |
BRACKET
|
1 |
superseded
|
| 18 |
856975 |
MOUNT
|
3 |
|
| 19 |
29395 |
WASHER (.390 x 1.00 x .06)
|
3 |
superseded
|
| 2 |
68229 |
WASHER (.641 x 1.250 x .190)
|
1 |
superseded
|
| 20 |
82446155 |
SCREW (M10 x 55)
|
1 |
|
| 21 |
4002319 |
WASHER
|
1 |
|
| 22 |
856583T2 |
CABLE ASSEMBLY
|
1 |
|
| 23 |
875285T1 |
ALTERNATOR Service Complete - Design I - 875285 Marked On Part
|
1 |
superseded
|
| 23 |
881248T |
ALTERNATOR Service Complete - Design II - 881248 Marked On Part
|
1 |
superseded
|
| 23 |
889955A03 |
ALTERNATOR KIT Service Complete - Design III - 889955 Marked On Part
|
1 |
superseded
|
| 24 |
858393T |
BRACKET
|
1 |
superseded
|
| 25 |
826292 |
NUT (M10) Brass/Nickel Plated
|
2 |
|
| 26 |
8268336 |
NUT (M6)
|
1 |
superseded
|
| 27 |
812618 |
SCREW (.312-18 x 1.00) Stainless Steel With Nylon Patch
|
3 |
|
| 28 |
857142T |
BRACKET Alternator Support
|
1 |
|
| 29 |
8215832 |
PIN Special (1.5 Inches)
|
1 |
|
| 3 |
52901 |
NUT (.625-18)
|
1 |
|
| 4 |
45907 |
PLUG Yellow
|
1 |
|
| 5 |
8285074 |
BELT Alternator
|
1 |
superseded
|
| 6 |
4010835 |
SCREW (M10 x 35) Hex Flange - Stainless Steel
|
1 |
|
| 7 |
852385A2 |
PULLEY ASSEMBLY Belt Tensioner
|
1 |
superseded
|
| 8 |
826292 |
NUT (M10) Brass/Nickel Plated
|
1 |
|
| 9 |
856900 |
STUD (M10 x 85)
|
1 |
superseded
|
