| # | Part Number | Description | Qty | Status |
|---|
| 1 |
814101 |
NUT (.250-20) Stainless Steel TORQUE 70 LB. IN. 7.8 N-M
|
1 |
superseded
|
| 10 |
824466A3 |
COVER ASSEMBLY Stop Switch
|
1 |
disc.
|
| 11 |
F2230 |
SCREW (#6-32 x .375) TORQUE 9 LB. IN. .98 N-M
|
4 |
disc.
|
| 12 |
F521690-1 |
SCREW (Special)-Throttle Lever Adjust
|
1 |
disc.
|
| 13 |
F7009 |
NUT (#10-24) TORQUE 30 LB. IN. 3.3 N-M
|
1 |
disc.
|
| 14 |
F2219 |
SCREW (#8-18 x .750) TORQUE 20 LB. IN. 2.2 N-M
|
3 |
disc.
|
| 15 |
827252 |
ARM Steering (LOWER)
|
1 |
superseded
|
| 16 |
F521199 |
SPRING Throttle Lever Adjust
|
1 |
disc.
|
| 17 |
F702198 |
STOP Idle
|
1 |
disc.
|
| 18 |
828070 |
GRIP Steering Handle
|
1 |
disc.
|
| 19 |
21836 |
O-RING (.796 x .139)
|
1 |
superseded
|
| 2 |
29245 |
WASHER (.281 x .500 x .060) Stainless Steel
|
1 |
superseded
|
| 20 |
F702178 |
RETAINER Grip
|
1 |
disc.
|
| 21 |
23145 |
O-RING (.984 x .139) Grip Rear
|
1 |
|
| 22 |
F702687 |
COLLAR Handle
|
1 |
disc.
|
| 23 |
F712894 |
DECAL Speed/Shift Indicator
|
1 |
disc.
|
| 24 |
F702384 |
RETAINER
|
1 |
disc.
|
| 25 |
824687 |
SPACER
|
1 |
disc.
|
| 26 |
F702504 |
GROMMET
|
1 |
disc.
|
| 27 |
F702212 |
PLATE Cable Clamp
|
1 |
disc.
|
| 3 |
F702668 |
RETAINER Speed Control Cable
|
1 |
disc.
|
| 4 |
F702035 |
BEARING Connector (#10-24 RH)
|
1 |
disc.
|
| 5 |
90192 |
SCREW (.250-20 x .750) Stainless Steel TORQUE 70 LB. IN. 7.8 N-M
|
1 |
|
| 6 |
F702444 |
CABLE ASSEMBLY Throttle
|
1 |
disc.
|
| 7 |
F702025 |
PAD Handle Bumper
|
1 |
disc.
|
| 8 |
F702079T1 |
ARM Steering (UPPER) (Painted)
|
1 |
disc.
|
| 9 |
824440A13 |
SWITCH KIT Stop
|
1 |
disc.
|
