| # | Part Number | Description | Qty | Status |
|---|
| - |
FG10341 |
GASKET SET Powerhead
|
1 |
|
| - |
819854A5 |
POWERHEAD ASSEMBLY
|
1 |
disc.
|
| 1 |
F521168 |
GASKET Carburetor Adapter
|
1 |
disc.
|
| 10 |
826625 |
STUD (.250-20 x 1.130) With Dri Lok
|
2 |
disc.
|
| 11 |
18678 |
WASHER
|
2 |
disc.
|
| 2 |
F712504 |
GROMMET Reed Plate
|
1 |
disc.
|
| 3 |
819677 |
PLATE Reed
|
1 |
disc.
|
| 4 |
F31160-2 |
REED
|
2 |
disc.
|
| 5 |
20890 |
NUT (.250-20) TORQUE 70 LB. IN. 7.8 N-M
|
2 |
|
| 6 |
819110100 |
SCREW (.250-20 x 1.00) TORQUE 70 LB. IN. 7.8 N-M
|
4 |
disc.
|
| 7 |
F8060 |
LOCKWASHER (.250 External)
|
2 |
disc.
|
| 8 |
F2008 |
SCREW (.250-20 x .875) TORQUE 70 LB. IN. 7.8 N-M
|
2 |
disc.
|
| 9 |
820097A1 |
ADAPTER ASSEMBLY Carburetor (Painted)
|
1 |
disc.
|
