| # | Part Number | Description | Qty | Status |
|---|
| 1 |
820194A1 |
PLATE ASSEMBLY Exhaust
|
1 |
disc.
|
| 10 |
430086 |
GASKET Exhaust Plate/Exhaust Tube
|
1 |
|
| 11 |
429666 |
TUBE Exhaust
|
1 |
disc.
|
| 12 |
4010725 |
SCREW (M8 x 25)
|
6 |
|
| 13 |
42962 |
SEAL Exhaust Tube
|
1 |
superseded
|
| 14 |
894171 |
GROMMET Water Tube Lower
|
1 |
superseded
|
| 15 |
8246601 |
TUBE Water (LONG)
|
1 |
superseded
|
| 15 |
8246602 |
TUBE Water (X-LONG)
|
1 |
superseded
|
| 16 |
4010750 |
SCREW (M8 x 50)
|
2 |
|
| 17 |
824661 |
CLAMP Water Tube
|
1 |
|
| 18 |
814080 |
SEAL Water Tube Upper
|
1 |
superseded
|
| 19 |
35459 |
WASHER
|
1 |
|
| 2 |
23784 |
PIN Dowel
|
5 |
|
| 20 |
400634 |
NUT (M6)
|
1 |
superseded
|
| 24 |
48237 |
BUSHING
|
1 |
|
| 25 |
79932A9 |
SHIFT SHAFT ASSEMBLY Shift Shaft
|
1 |
disc.
|
| 26 |
820278A1 |
LINK ASSEMBLY Shift
|
1 |
disc.
|
| 27 |
48475 |
BUSHING
|
1 |
|
| 28 |
400634 |
NUT (M6)
|
1 |
superseded
|
| 29 |
43041 |
SPACER (LONG)
|
1 |
superseded
|
| 29 |
11289 |
SPACER (X-LONG)
|
1 |
|
| 3 |
4008920 |
SCREW (M8 x 20) Stainless Steel
|
3 |
|
| 31 |
43585 |
COUPLING
|
1 |
|
| 4 |
429492 |
MOUNT (2.375 Inch) (LONG)
|
1 |
superseded
|
| 4 |
443442 |
MOUNT (2.375 Inch) (X-LONG)
|
1 |
superseded
|
| 5 |
4010750 |
SCREW (M8 x 50)
|
4 |
|
| 6 |
42974 |
BOLT (M12 x 175)
|
2 |
superseded
|
| 7 |
93416 |
WASHER
|
2 |
superseded
|
| 8 |
28421 |
WASHER (1.5 x 3.05 x 0.13) Stainless Steel
|
2 |
superseded
|
| 9 |
90099 |
NUT (M12)
|
2 |
superseded
|
