| # | Part Number | Description | Qty | Status |
|---|
| - |
92040A89 |
POWERHEAD ASSEMBLY (250)
|
1 |
disc.
|
| - |
19398A93 |
POWERHEAD ASSEMBLY (275)
|
1 |
disc.
|
| - |
88605A89 |
GASKET SET
|
1 |
disc.
|
| 1 |
88834 |
BRACKET
|
1 |
disc.
|
| 10 |
38407 |
PLUG (.500-14)
|
1 |
|
| 11 |
90435 |
MOUNT
|
4 |
|
| 12 |
29245 |
WASHER (.281 x .500 x .060) Stainless Steel
|
8 |
superseded
|
| 13 |
35888 |
NUT (.250-28) Stainless Steel
|
8 |
|
| 14 |
41020A3 |
CYLINDER HEAD
|
2 |
disc.
|
| 15 |
88251 |
SEAL
|
2 |
disc.
|
| 16 |
88923 |
O-RING
|
6 |
disc.
|
| 17 |
81742780 |
SCREW (M8 x 80)
|
48 |
|
| 17 |
81516050 |
SCREW (50 MM)
|
48 |
disc.
|
| 18 |
47483 |
J CLIP
|
3 |
|
| 19 |
14586 |
THERMOSTAT (120 DEGREES)
|
2 |
|
| 2 |
81516030 |
SCREW (30 MM)
|
1 |
disc.
|
| 20 |
62386 |
GASKET
|
2 |
superseded
|
| 21 |
90390A1 |
COVER KIT
|
2 |
|
| 22 |
74824 |
SCREW (.312-18 x 1.250)
|
4 |
|
| 23 |
68727 |
FITTING (.250-18) 90 Degree - Brass
|
2 |
superseded
|
| 24 |
7765377 |
HOSE (24.500 Inches Bulk)
|
2 |
superseded
|
| 25 |
91836 |
TEE
|
1 |
disc.
|
| 26 |
816311 |
TIE STRAP (8.00 Inches)
|
AR |
superseded
|
| 27 |
7765377 |
HOSE (24.500 Inches Bulk) (3")
|
1 |
superseded
|
| 28 |
99127109 |
LINE (57.00 Inches Bulk) TELL TAIL (4")
|
1 |
superseded
|
| 29 |
76256 |
NOZZLE
|
1 |
disc.
|
| 3 |
15093 |
STUD (#10-32 x 1.00)
|
4 |
superseded
|
| 3 |
69016 |
STUD (1.44")
|
4 |
disc.
|
| 30 |
12415 |
SENDER Temperature
|
1 |
|
| 31 |
68307 |
PLUG
|
1 |
|
| 4 |
49221 |
WASHER (.187 x .500 x .062) Neoprene (LARGE)
|
8 |
superseded
|
| 5 |
22887 |
WASHER (SMALL)
|
8 |
disc.
|
| 6 |
816874 |
WING NUT (#10-32)
|
4 |
|
| 7 |
94110A1 |
COVER (SEE DESIGN I DRAWING)
|
1 |
disc.
|
| 7 |
941103 |
COVER (SEE DESIGN II DRAWING)
|
1 |
disc.
|
| 8 |
940601 |
GASKET
|
1 |
disc.
|
| 9 |
81516025 |
SCREW (25 MM)
|
17 |
superseded
|
