| # | Part Number | Description | Qty | Status |
|---|
| - |
88605A89 |
GASKET SET
|
1 |
disc.
|
| 1 |
8M0027773 |
PLATE-PORT (PORT)
|
3 |
disc.
|
| 10 |
90198 |
SCREW
|
12 |
superseded
|
| 11 |
30720 |
SCREW (.250-20 x 2.25)
|
12 |
disc.
|
| 12 |
28635 |
SCREW (.250-20 x .620) Stainless Steel
|
12 |
|
| 13 |
81516025 |
SCREW
|
22 |
superseded
|
| 14 |
815158 |
STUD
|
12 |
disc.
|
| 15 |
4002217 |
WASHER
|
12 |
|
| 16 |
400265 |
NUT (M8)
|
12 |
superseded
|
| 17 |
933531 |
GASKET
|
6 |
disc.
|
| 18 |
88586 |
LINK Throttle
|
2 |
disc.
|
| 19 |
895981 |
LEVER Throttle
|
1 |
disc.
|
| 2 |
886252 |
GASKET (PORT)
|
3 |
disc.
|
| 20 |
6027 |
SCREW
|
1 |
disc.
|
| 21 |
67748 |
ROLLER
|
1 |
|
| 22 |
88585 |
LEVER Throttle
|
1 |
disc.
|
| 23 |
67297 |
PIN Clevis
|
7 |
|
| 24 |
26953 |
COTTER PIN
|
7 |
|
| 25 |
27736 |
WASHER
|
7 |
superseded
|
| 26 |
88584 |
LEVER Throttle
|
5 |
disc.
|
| 27 |
92501 |
SCREW
|
6 |
superseded
|
| 28 |
26996 |
LOCKWASHER (#10) Stainless Steel
|
6 |
|
| 29 |
24676 |
WASHER (.200 x .440 x .032)
|
6 |
|
| 3 |
8M0027810 |
PLATE-STBD (STARBOARD)
|
3 |
disc.
|
| 30 |
99127109 |
LINE (57.00 Inches Bulk)
|
1 |
superseded
|
| 31 |
16961 |
FITTING
|
1 |
disc.
|
| 32 |
817518 |
TEE
|
1 |
disc.
|
| 33 |
9912688 |
TUBING (36.00 Inches Bulk)
|
1 |
|
| 34 |
42859A2 |
VALVE ASSEMBLY Enrichner
|
1 |
|
| 35 |
633001 |
CLAMP
|
1 |
disc.
|
| 36 |
28635 |
SCREW (.250-20 x .620) Stainless Steel
|
1 |
|
| 37 |
26992 |
LOCKWASHER (.250) Stainless Steel
|
1 |
|
| 38 |
64015 |
NUT (.250-20)
|
1 |
|
| 39 |
9912980 |
HOSE
|
1 |
superseded
|
| 4 |
886262 |
GASKET (STARBOARD)
|
3 |
disc.
|
| 40 |
8162961 |
FILTER Fuel
|
1 |
superseded
|
| 41 |
816311 |
TIE STRAP (8.00 Inches)
|
AR |
superseded
|
| 5 |
20500 |
STUD
|
1 |
disc.
|
| 6 |
35888 |
NUT (.250-28) Stainless Steel
|
1 |
|
| 7 |
884293 |
ADAPTER
|
6 |
disc.
|
| 8 |
657443 |
GASKET
|
12 |
|
| 9 |
11645 |
REED BLOCK (INCLUDES REEDS/REED STOP & SCREWS)
|
12 |
superseded
|
