| # | Part Number | Description | Qty | Status |
|---|
| 1 |
918822 |
IGNITION PLATE
|
1 |
disc.
|
| 10 |
38055 |
SCREW (.190-32 x .620)
|
1 |
disc.
|
| 11 |
45076 |
NUT (#10-32) Brass
|
1 |
|
| 12 |
36242 |
PIN Roll
|
2 |
disc.
|
| 13 |
66986 |
TERMINAL BLOCK
|
1 |
disc.
|
| 14 |
22523 |
SCREW (.190-32 x .75)
|
1 |
disc.
|
| 15 |
37572 |
SCREW (.190-32 x .380)
|
1 |
|
| 16 |
92432A7 |
HARNESS ASSEMBLY Engine Wiring (USE W/815279T REGULATOR)
|
1 |
disc.
|
| 16 |
92432A6 |
HARNESS ASSEMBLY Engine Wiring
|
1 |
disc.
|
| 17 |
79091 |
FUSE 20 Ampere
|
1 |
superseded
|
| 18 |
134731 |
HOLDER Fuse (OLD DESIGN)
|
1 |
disc.
|
| 19 |
78799 |
SENDER Temperature (19.50 Inch)
|
1 |
|
| 2 |
82127335 |
SCREW (M8 x 35 MM)
|
3 |
|
| 20 |
13899 |
RING Snap
|
1 |
disc.
|
| 21 |
88751 |
CLAMP
|
1 |
disc.
|
| 22 |
28636 |
SCREW (.250-20 x .750)
|
1 |
|
| 23 |
20533 |
WASHER
|
1 |
|
| 24 |
88824A9 |
CABLE ASSEMBLY (TAN - 25")
|
1 |
disc.
|
| 24 |
88807A21 |
CABLE ASSEMBLY (BLACK -4-1/2")
|
1 |
disc.
|
| 24 |
88807A38 |
CABLE ASSEMBLY (24")
|
1 |
disc.
|
| 25 |
14857A7 |
MODULE ASSEMBLY Oil Warning
|
1 |
superseded
|
| 26 |
4010630 |
SCREW (M6 x 30) Stainless Steel
|
2 |
|
| 27 |
4002316 |
WASHER (6.60 X 17.0 X 1.5SS)
|
2 |
superseded
|
| 28 |
88439A14 |
CABLE ASSEMBLY Battery - Positive
|
1 |
|
| 28 |
88439A2 |
CABLE ASSEMBLY Battery - Negative
|
1 |
|
| 29 |
68258A4 |
SOLENOID ASSEMBLY Starter
|
1 |
superseded
|
| 3 |
53166 |
LOCKWASHER (.312)
|
3 |
|
| 30 |
45076 |
NUT (#10-32) Brass
|
2 |
|
| 31 |
39107 |
LOCKWASHER (.312-24)
|
1 |
|
| 32 |
93389A2 |
WIRE (YELLOW)
|
1 |
disc.
|
| 33 |
68292 |
NUT (.312-18)
|
1 |
superseded
|
| 34 |
90198 |
SCREW (5/8")
|
2 |
superseded
|
| 35 |
26992 |
LOCKWASHER (.250) Stainless Steel
|
2 |
|
| 36 |
86926A11 |
SPEED LIMITER ASSEMBLY
|
1 |
disc.
|
| 37 |
40019108 |
SCREW (M5 x 20)
|
1 |
disc.
|
| 38 |
42551A1 |
DIODE ASSEMBLY
|
1 |
disc.
|
| 39 |
7778A12 |
SWITCHBOX ASSEMBLY
|
2 |
|
| 4 |
65999A2 |
CABLE ASSEMBLY Black
|
2 |
disc.
|
| 40 |
90818 |
SCREW
|
4 |
disc.
|
| 41 |
91912 |
BUSHING
|
4 |
disc.
|
| 42 |
45076 |
NUT (#10-32) Brass
|
20 |
|
| 43 |
69079 |
SCREW (#10-16 x .440)
|
2 |
|
| 44 |
92485A2 |
HARNESS ASSEMBLY COIL TO SWITCH BOX (#2, 4 AND 6)
|
1 |
disc.
|
| 44 |
92486A2 |
HARNESS ASSEMBLY COIL TO SWITCH BOX (#1,3 AND 5)
|
1 |
disc.
|
| 45 |
5790811 |
SLEEVE (10.00 Inches Bulk)
|
1 |
|
| 5 |
47483 |
J CLIP (1/2")
|
1 |
|
| 6 |
36042 |
WASHER
|
6 |
|
| 7 |
67264 |
WASHER (Rubber)
|
6 |
|
| 8 |
67268 |
BUSHING
|
3 |
disc.
|
| 9 |
33386A3 |
SWITCH ASSEMLBY
|
1 |
disc.
|
