| # | Part Number | Description | Qty | Status |
|---|
| - |
824326A02 |
GASKET SET
|
1 |
|
| 1 |
805185A37 |
DISTRIBUTOR ASSEMBLY
|
1 |
|
| 10 |
47617 |
PIN
|
1 |
|
| 11 |
90931 |
THRUST WASHER
|
1 |
|
| 12 |
344863 |
GASKET
|
1 |
|
| 13 |
52185 |
CLAMP
|
1 |
superseded
|
| 14 |
806681 |
SCREW (.375-16 x .875)
|
1 |
|
| 15 |
816761Q16 |
CABLE KIT Spark Plugs And Coil
|
1 |
|
| 16 |
63709A1 |
BOOT/TERMINAL KIT
|
8 |
|
| 17 |
816336Q |
SPARK PLUG
|
6 |
|
| 18 |
805570A2 |
COIL KIT
|
1 |
superseded
|
| 19 |
65970T1 |
BRACKET
|
1 |
|
| 2 |
815407A2 |
CAP Distributor
|
1 |
|
| 20 |
41408 |
SCREW (#10-32 x 1.50)
|
1 |
|
| 21 |
26996 |
LOCKWASHER (#10) Stainless Steel
|
2 |
|
| 22 |
68219 |
NUT (#10-32) Stainless Steel
|
2 |
|
| 23 |
98261 |
SCREW (.375-16 x .750)
|
1 |
|
| 24 |
20553 |
WASHER (.406 x .734 x .063)
|
1 |
|
| 25 |
90096A1 |
STUD ASSEMBLY (#10-32 x Special)
|
2 |
|
| 26 |
72821 |
RETAINER
|
2 |
|
| 3 |
90926 |
SCREW (#10-32 x .810)
|
4 |
|
| 4 |
805760 |
GASKET
|
1 |
|
| 5 |
13524A6 |
ROTOR/SENSOR WHEEL
|
1 |
|
| 6 |
892150Q02 |
SENSOR ASSEMBLY
|
1 |
|
| 7 |
66686 |
SCREW (#10-32 x 1.00)
|
1 |
|
| 7 |
72202 |
SCREW (#10-32 x 1.25)
|
1 |
|
| 8 |
26996 |
LOCKWASHER (#10) Stainless Steel
|
2 |
|
| 9 |
818807 |
GEAR
|
1 |
superseded
|
