| # | Part Number | Description | Qty | Status |
|---|---|---|---|---|
| 1 | 806193A13 |
РЕЗЕРВУАР RESERVOIR |
1 | superseded |
| 10 | 91034 |
ПРОСТАВКА (0.380 x 1.00 x 0.530) SPACER (.380 x 1.00 x .530) |
1 | |
| 11 | 26486 |
ВИНТ (0.375-16 x 2.375) SCREW (.375-16 x 2.375) |
1 | |
| 12 | 20553 |
ШАЙБА (0.406 x 0.734 x 0.063) WASHER (.406 x .734 x .063) |
1 | |
| 13 | 15895 |
ПРОСТАВКА (0.38 x 1.00 x 1.44) SPACER (.38 x 1.00 x 1.44) |
1 | disc. |
| 2 | 808625 |
ПРОБКА Монитор смазки привода Oil Bottle CAP Drive Lube Monitor Oil Bottle |
1 | superseded |
| 3 | 808624 |
СОЕДИНИТЕЛЬ CONNECTOR |
1 | |
| 4 | 860065A1 |
КОМПЛЕКТ КРОНШТЕЙНА Oil Bottle BRACKET KIT Oil Bottle |
1 | |
| 5 | 808023T |
СКОБА Bracket STRAP Bracket |
1 | |
| 6 | 805367T |
КРОНШТЕЙН BRACKET |
1 | |
| 7 | 29250 |
ГАЙКА (0.312-24) NUT (.312-24) |
2 | |
| 8 | 37612 |
ВИНТ (0.375-16 x 1.250) SCREW (.375-16 x 1.250) |
1 | |
| 9 | 35048 |
СТОПОРНАЯ ШАЙБА (0.375) LOCKWASHER (.375) |
2 |
